Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCT
-
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, Internal Routing, Smooth Welds
Suspension Fork
Suntour XCT30 HLO DS, 100mm, 42mm Offset (27.5), 46mm Offset (29)
Drivetrain
Rear Derailleur
Shimano Alivio RD-M3100 Shadow
Front Derailleur
Shimano Altus FD-M2020
Shift Levers
Shimano Alivio SL-M3100
Cassette
Shimano Acera CS-HG2009, 11-36T, 9 Speed
Crank
Prowheel ZEPHYR-501, 36/22T, 170mm (XXS, XS, S), 175mm (M, L, XL)
Bottom Bracket
Cartridge, BSA Threaded
Chain
KMC Z99
Pedals
VP Nylon Flat
Wheels
Front Hub
Alloy QR, 9x100mm QR, 6 Bolt
Rear Hub
Alloy QR, 10x135mm QR, HG, 6 Bolt
Rims
WTB SX19
Tires
Front: Maxxis Rekon DK60 2.25", Rear: Maxxis Rekon DK60 2.25"
Brakes
Brakes
Front: Tektro HD-M275 Hydraulic, Resin Pads, Rear: Tektro HD-M275 Hydraulic, Resin Pads
Brake Levers
Tektro HD-M275, HD-M276 Short Reach on Step-Thru
Cockpit
Stem
Alloy 60mm, 31.8mm Clamp
Handlebar
X6 Alloy, 720mm (XXS, XS, S), 740mm (M, L, XL), 25mm Rise
Grips
Norco
Headset
Zero Stack
Seat
Saddle
Norco XC
Seatpost
Alloy 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.39 mm | 1.32 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm |
| Front Center | 703 mm | 737 mm | 771 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 92 mm | 92 mm | 92 mm |
| Stack | 626 mm | 635 mm | 645 mm |
| Reach | 427 mm | 457 mm | 487 mm |
| Top Tube Length | 594 mm | 627 mm | 659 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1148 mm | 1182 mm | 1216 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm |
| Standover Height | 688 mm | 723 mm | 756 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 175 cm | 184 cm | 191 cm |
About this model
Storm 3 29 belongs to the Norco Storm model. Norco launched 177 bikes of this model so far. Take a sneak peek at all Norco Storm bikes models from 2023, by clicking here.
Model range prices
Norco Storm 14 SS 2023 is the most economical model, with a starting price of 361$. Norco Storm 1 29 2023 on the other hand costs 1049$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 799$. Doing a quick comparison, we notice that Storm 3 29 price is 138.42% smaller than the average cost of a Crosscountry bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Storm 3 29 components
Fork
The Storm 3 29 comes factory-installed with the Suntour XCT fork. This has a travel range of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The Storm 3 29 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Storm 3 29 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Norco Storm 3 29 bike has 3 sizes, in the range of 163 cm – 191 cm (5.35 ft – 6.27 ft). In conclusion, it won’t take much to find one that’s right for you.
