Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 50mm -
Fork SunTour XCT
-
Groupset Altus -
Suspension Hardtail -
Drivetrain 1 × 7 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Lightweight aluminum low standover frame
Suspension Fork
SR Suntour XCT Jr. coil spring suspension 50mm travel with preload adjuster
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Altus RD M310SGS direct mount
Front Derailleur
N/A
Shift Levers
N/A
Cassette
Shimano Tourney TZ31 14-34T 7-Spd
Crank
Aluminum narrow-wide 28T 3-pc crankset - Black
Bottom Bracket
Cartridge bearing square taper BB
Pedals
Alloy cage Jr. MTB pedal 9/16" w/bearing"
Wheels
Front Hub
KT aluminum disc 32H MTB hub w/ball bearing
Rear Hub
KT aluminum disc 32H MTB rear hub w/ball bearing
Rims
Aluminum double wall 24" MTB"
Tires
24" x 1.95"" with MTB tread"
Brakes
Brakes
Tektro mechanical disc brakes w/160mm rotor
Brake Levers
Tektro Jr. MTB alloy/resin front and rear levers w/reach adjust
Cockpit
Stem
Kalloy 35mm ext., 1-1/8" threadless MTB"
Handlebar
Jr. MTB aluminum 680mm wide x 30mm rise
Grips
Jr. MTB type, soft krayton rubber
Seat
Saddle
Norco Jr. MTB saddle with cutaway design
Seatpost
Aluminum with micro adjust top, 250mmx27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | N/A |
|---|---|
| Stack Reach Ratio | 1.64 mm |
| Bottom Bracket Height | 270 mm |
| Front Center | 539 mm |
| Rake | 65 mm |
| Stack | 514 mm |
| Reach | 314 mm |
| Top Tube Length | 484 mm |
| Seat Tube Angle | 72 ° |
| Seat Tube Length | 290 mm |
| Head Tube Angle | 70 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 372 mm |
| Wheelbase | 937 mm |
| Bottom Bracket Drop | 40 mm |
| Standover Height | 507 mm |
| Front Travel | 50 mm |
| Wheels | 24" |
About this model
Storm 4.1 belongs to the Norco Storm model. 177 frames variations carry this model name so far. Take a sneak peek at all Norco Storm frames models from 2017, by clicking here.
Model range prices
Norco Storm 2.3 2017 is the cheapest frame model and costs 269$. Norco Storm 4.1 2017 is the most expensive one and costs 449$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Mountain frames average price
According to our math, the average price for a trustworthy Mountain frame is 514$. However, even if your budget is less than the average, you might still be able to get a top-quality Mountain frame. To make sure you don’t pay a higher amount than normal for your frame, always do some components analysis and read reviews.
This frame was released in 2017 and its price was 449$. Comparing this to the average Mountain frame price, we see that the price is 14.48% smaller.
Overview of components
Fork
The fork installed on this bike is the SunTour XCT model. The travel on this model is 50mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Storm 4.1 is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
