Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCE
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XXS
137cm - 148cm
XS
145cm - 157cm
SM
154cm - 166cm
MD
163cm - 174cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, Internal Routing, Smooth Welds
Suspension Fork
Suntour XCE28 100mm, 42mm Offset (27.5), 46mm Offset (29)
Drivetrain
Rear Derailleur
Shimano Tourney RD-TX300
Front Derailleur
Shimano Tourney FD-TY500
Shift Levers
Shimano TX ST-EF500
Cassette
SunRace, 11-34T, 7 Speed
Crank
Shimano TY301, 42/34/24T, 170mm (XXS, XS, S), 175mm (M, L, XL)
Bottom Bracket
Cartridge, BSA Threaded
Chain
KMC Z7
Pedals
VP Nylon Flat
Wheels
Front Hub
Alloy QR, 9x100mm QR, 6 Bolt
Rear Hub
Alloy QR, 10x135mm QR, HG, 6 Bolt
Rims
WTB SX19
Tires
Front: WTB Starflight 2.25", Rear: WTB Starflight 2.25"
Brakes
Brakes
Front: C-Star Mechanical Disc Brake, Rear: C-Star Mechanical Disc Brake
Brake Levers
Shimano EF500 Tourney
Cockpit
Stem
Alloy 60mm, 31.8mm Clamp
Handlebar
X6 Alloy, 720mm (XXS, XS, S), 740mm (M, L, XL), 25mm Rise
Grips
Norco
Headset
Zero Stack
Seat
Saddle
Norco XC
Seatpost
Alloy 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD |
|---|---|---|---|---|
| Stack Reach Ratio | 1.79 mm | 1.67 mm | 1.56 mm | 1.46 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 310 mm |
| Front Center | 602 mm | 636 mm | 326 mm | 703 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 98 mm | 98 mm | 98 mm | 98 mm |
| Stack | 583 mm | 593 mm | 602 mm | 606 mm |
| Reach | 326 mm | 356 mm | 386 mm | 416 mm |
| Top Tube Length | 485 mm | 517 mm | 550 mm | 581 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 340 mm | 390 mm | 430 mm | 470 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1023 mm | 1057 mm | mm | 1125 mm |
| Bottom Bracket Drop | 49 mm | 49 mm | 49 mm | 44 mm |
| Standover Height | 579 mm | 607 mm | 623 mm | 664 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 137 cm | 145 cm | 154 cm | 163 cm |
| Rider Max Height | 148 cm | 157 cm | 166 cm | 174 cm |
Model Overview
Storm 5 27.5 is a Norco Storm model. Norco launched 177 bikes of this model so far. You can easily view all of the Norco Storm bikes models from 2023, here.
Model range prices
Norco Storm 14 SS 2023 is the most economical model, with a starting price of 361$. Norco Storm 1 29 2023 on the other hand costs 1049$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Norco released this model in 2023, its price was 599$. If we compare this with the average Crosscountry bike cost we notice that the price is 218.03% lower.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Storm 5 27.5 components
Fork
Norco Storm 5 27.5 2023 bike is equipped with the Suntour XCE fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The Storm 5 27.5 2023 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Storm 5 27.5 has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Storm 5 27.5 comes in 4 sizes, that range from 137 cm – 174 cm (4.49 ft – 5.71 ft). In conclusion, finding one for you shouldn’t be a problem.
