Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCE
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, Internal Routing, Smooth Welds
Suspension Fork
Suntour XCE28 100mm, 42mm Offset (27.5), 46mm Offset (29)
Drivetrain
Rear Derailleur
Shimano Tourney RD-TX300
Front Derailleur
Shimano Tourney FD-TY500
Shift Levers
Shimano TX ST-EF500
Cassette
SunRace, 11-34T, 7 Speed
Crank
Shimano TY301, 42/34/24T, 170mm (XXS, XS, S), 175mm (M, L, XL)
Bottom Bracket
Cartridge, BSA Threaded
Chain
KMC Z7
Pedals
VP Nylon Flat
Wheels
Front Hub
Alloy QR, 9x100mm QR, 6 Bolt
Rear Hub
Alloy QR, 10x135mm QR, HG, 6 Bolt
Rims
WTB SX19
Tires
Front: WTB Starflight 2.25", Rear: WTB Starflight 2.25"
Brakes
Brakes
Front: C-Star Mechanical Disc Brake, Rear: C-Star Mechanical Disc Brake
Brake Levers
Shimano EF500 Tourney
Cockpit
Stem
Alloy 60mm, 31.8mm Clamp
Handlebar
X6 Alloy, 720mm (XXS, XS, S), 740mm (M, L, XL), 25mm Rise
Grips
Norco
Headset
Zero Stack
Seat
Saddle
Norco XC
Seatpost
Alloy 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.39 mm | 1.32 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm |
| Front Center | 703 mm | 737 mm | 771 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 92 mm | 92 mm | 92 mm |
| Stack | 626 mm | 635 mm | 645 mm |
| Reach | 427 mm | 457 mm | 487 mm |
| Top Tube Length | 594 mm | 627 mm | 659 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1148 mm | 1182 mm | 1216 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm |
| Standover Height | 688 mm | 723 mm | 756 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 175 cm | 184 cm | 191 cm |
About this model
Storm 5 29 is part of the Norco Storm model. Norco released 177 bikes variations of this model so far. Take a sneak peek at all Norco Storm bikes models from 2023, by clicking here.
Model range prices
Norco Storm 14 SS 2023 is the most affordable bike of this model and has a price of 361$. On the other hand, Norco Storm 1 29 2023, is the most expensive and costs 1049$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Norco Storm 5 29 price was 599$. Comparing the average cost of a Crosscountry bike to this one, you will see that Storm 5 29 price is 218.03% smaller.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
This bike has the Suntour XCE fork installed. The fork’s travel is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
As for the wheels, Norco Storm 5 29 2023, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Storm 5 29 has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Norco Storm 5 29 bike has 3 sizes, in the range of 163 cm – 191 cm (5.35 ft – 6.27 ft). In conclusion, finding one for you shouldn’t be a problem.
