Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset 105, SRAM -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Threshold Cross 30T High-Mod Carbon - Disc
Suspension Fork
Threshold Full Carbon Tapered w/PM-Disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano 105 RD-5701 - Black
Front Derailleur
Shimano 105 FD-5700L - Black
Shift Levers
Shift Housing - White
Cassette
Shimano CS-4600 12-28T 10 speed
Crank
SRAM S350 PF30 46/36 - Mirror Black
Bottom Bracket
SRAM PressFit30
Chain
SRAM CN-PC1031 10speed
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
SRAM 306 Disc Hub - Black
Rear Hub
SRAM 306 Disc Hub - Black
Rims
Alex ATD490 Disc - Black
Tires
Clement Crusade PDX 700 x 33c
Brakes
Brakes
Hayes CX-5 Mechanical Disc w/140mm rotor
Brake Levers
Shimano 105 ST-5700 - Black
Disk Rotors
N/A
Cockpit
Stem
Norco - Black w/White
Handlebar
Norco Compact - Black w/White
Grips
Norco Anti-Slip Tape - Black
Headset
FSA No.42B/Cup Tapered w/9mm Cone Spacer
Seat
Saddle
Norco Cross Race - Black w/White
Seatpost
Norco Alloy 27.2mm - Black w/White
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 53cm | 56cm | 59cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.44 mm | 1.48 mm | 1.48 mm | 1.5 mm |
| Bottom Bracket Height | 281.5 mm | 294 mm | 294 mm | 294 mm | 294 mm |
| Front Center | 589 mm | 590 mm | 594 mm | 609 mm | 621 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 71 mm | 67 mm | 62 mm | 59 mm | 58 mm |
| Stack | 534 mm | 543 mm | 564 mm | 585 mm | 605 mm |
| Reach | 374 mm | 377 mm | 381 mm | 394 mm | 403 mm |
| Top Tube Length | 523 mm | 533 mm | 548 mm | 568 mm | 588 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 500 mm | 530 mm | 560 mm | 590 mm | 610 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.3 ° | 72.8 ° | 73 ° |
| Head Tube Length | 115 mm | 125 mm | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1003 mm | 1005 mm | 1008 mm | 1023 mm | 1036 mm |
| Bottom Bracket Drop | 67 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 769 mm | 783 mm | 806 mm | 828 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Threshold C2 is part of the Norco Threshold model. 58 bikes variations carry this model name so far. Check out the entire range from 2014 of this model, by clicking this link.
Model range prices
The most economical model, the Norco Threshold A3 2014 has a starting price of 860$. Norco Threshold SL 2014 on the other hand is the most expensive at 5110$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Cyclocross bikes
If you want an acceptable Cyclocross bike you should know that the average price is 2012$. However, this doesn’t mean that if you spend less money on a Cyclocross bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2050$. Doing a quick comparison, we notice that Threshold C2 price is 1.89% higher than the average cost of a Cyclocross bike.
Overview of components
Fork material
Threshold C2 has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When leaving the production line, the Threshold C2 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Threshold C2 has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
