Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 29" -
Travel Front 180mm -
Fork RockShox
-
Groupset X7, SLX -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
2012 Truax 1 frame
Suspension Fork
Rockshox Totem Coil RC 180 mm travel
Rear Shock
Fox Van R coil with rebound adjust
Drivetrain
Rear Derailleur
SRAM X7 rear derailleur
Front Derailleur
Shimano SLX E-type (chainstay mount)
Shift Levers
SRAM X7 (2 speed front)
Cassette
SRAM PG-950 9 speed cassette
Crank
FSA Moto X mega Exo
Bottom Bracket
N/A
Chain
SRAM chain (PC-951)
Chain Tensioner
Black Spire Stinger
Pedals
Wellgo LU-A18 U with replaceable pins
Wheels
Front Hub
Formula 20 mm front hub
Rear Hub
Formula 142 x 12 rear hub DL-142
Rims
Sun Inferno 29 black anodized
Spokes
Shadar black stainless spokes 2.0
Tires
60 TPI folding bead Nevagal tires 2.35
Brakes
Brakes
Avid Elixer 5 with 203 mm rotor, white colour
Brake Levers
203 mm front rotor G3 CS
Cockpit
Stem
FSA Gap Stem short reach, forged alloy
Handlebar
Norco alloy 25 mm rise bar x 760 mm width butted
Grips
Velo Norco Lock on grips
Headset
Norco alloy 25 mm rise bar x 760 mm width butted
Seat
Saddle
WTB Silverado Comp OE
Seatpost
Norco Lite alloy MTB 2 bolt seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 355 mm | 355 mm | 355 mm |
| Front Center | 698 mm | 719 mm | 745 mm |
| Top Tube Length | 572 mm | 592 mm | 617 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 405 mm | 445 mm | 470 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1143 mm | 1164 mm | 1190 mm |
| Bottom Bracket Drop | 19 mm | 19 mm | 19 mm |
| Standover Height | 754 mm | 770 mm | 778 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Truax 1 completes the Norco Truax model. There are 10 bikes that carry this model name. You can easily view all of the Norco Truax bikes models from 2011, here.
Model range prices
Norco Truax 1 2011 is the most economical model, with a starting price of 3745$. Norco Truax Team 2011 on the other hand costs 5190$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Downhill bikes
If you want to purchase a solid Downhill bike, it is important to know that the average cost is 3391$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Downhill bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Norco Truax 1 price was 3745$. Comparing the average cost of a Downhill bike to this one, you will see that Truax 1 price is 10.44% higher.
Overview of components
Fork
The fork installed on this bike is the RockShox model. The travel on this model is 180mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When leaving the production line, the Truax 1 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Truax 1 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
