Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork SunTour NRX D
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
XFR Double Butted X6 Alloy w/CS Disc and Flip
Suspension Fork
SR Suntour NRX-D 75mm w/remote LO
Drivetrain
Rear Derailleur
Shimano Deore RD-M6000 Shadow - Black
Front Derailleur
Shimano Deore FD-T6000 - Black
Shift Levers
Rear: Shimano Deore SL-M6000 10spd - Black, Front: Shimano Deore SL-M6000 3spd - Black
Cassette
Shimano CS-HG500 10spd 11-34T
Crank
Shimano Deore FC-T6010 48/36/26T - Black
Bottom Bracket
Shimano HollowTech II
Chain
KMC X10 10spd
Pedals
City - Alloy
Wheels
Front Hub
Shimano Center Lock - Black
Rear Hub
Shimano Center Lock - Black
Rims
WTB SX19 - Black
Tires
Schwalbe Hurricane 700x40c w/RaceGuard
Brakes
Brakes
Shimano Deore BR-MT500 Discs w/160mm Rotor
Brake Levers
Shimano Deore BR-MT500
Cockpit
Stem
Norco SL Alloy - Black
Handlebar
Norco 25mm Riser - Black
Grips
Norco Grip
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
Norco MTB Race - Black
Seatpost
Norco Alloy 27.2mm - Black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.7 mm | 1.65 mm | 1.6 mm | 1.56 mm | 1.52 mm | 1.49 mm |
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm | 291 mm | 291 mm | 291 mm |
| Front Center | 611 mm | 626 mm | 642 mm | 658 mm | 679 mm | 699 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 47 mm |
| Trail | 81 mm | 78 mm | 75 mm | 72 mm | 72 mm | 70 mm |
| Stack | 608 mm | 619 mm | 629 mm | 640 mm | 649 mm | 659 mm |
| Reach | 358 mm | 375 mm | 392 mm | 409 mm | 426 mm | 443 mm |
| Top Tube Length | 526 mm | 551 mm | 576 mm | 601 mm | 626 mm | 651 mm |
| Seat Tube Angle | 74.5 ° | 74.1 ° | 73.7 ° | 73.3 ° | 72.9 ° | 72.5 ° |
| Seat Tube Length | 350 mm | 390 mm | 430 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 100 mm | 107.5 mm | 115 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1058 mm | 1074 mm | 1089 mm | 1107 mm | 1127 mm | 1148 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 712 mm | 739 mm | 763 mm | 798 mm | 821 mm | 843 mm |
| Front Travel | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
XFR 1 completes the Norco Xfr model. There are 76 bikes that carry this model name. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
Norco XFR 5 Step-Thru 2018 is the cheapest bike model and costs 399$. Norco XFR 1 2018 is the most expensive one and costs 999$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Hybrid bikes
If you want an acceptable Hybrid bike you should know that the average price is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Norco released this model in 2018, its price was 999$. Comparing the average cost of a Hybrid bike to this one, you will see that XFR 1 price is 77.76% more expensive.
Overview of components
Fork
This bike has the SunTour NRX D fork installed. The fork’s travel is 75mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When it comes to wheels, the XFR 1 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco XFR 1 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
