Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork SunTour
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XXS
145cm - 159cm
XS
157cm - 168cm
SM
165cm - 176cm
MD
174cm - 183cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
XFR Double Butted X6 Alloy Step-Thru
Suspension Fork
SR Suntour M-3030 75mm
Drivetrain
Rear Derailleur
Shimano RD-TY500
Front Derailleur
Shimano FD-TY510
Shift Levers
Rear: Shimano ST-EF500 Easy-Fire 7spd - Black, Front: Shimano ST-EF500 Easy-Fire 3spd - Black
Cassette
Shimano HG200 12-32T 7spd
Crank
Shimano FC-TY301 48/38/28T - Black
Bottom Bracket
Cartridge Bearing BB
Chain
KMC Z-50
Pedals
City - Black
Wheels
Front Hub
Alloy Sealed Disc Hub
Rear Hub
Alloy Sealed Disc Hub
Rims
WTB SX19 - Black
Tires
Impac CrossPac 700x38c
Brakes
Brakes
Tektro Mechanical Disc w/160mm rotor
Brake Levers
Shimano Easy-Fire w/2-finger lever
Cockpit
Stem
Alloy - Black
Handlebar
Norco Alloy 15mm Riser - Black
Grips
Slim Grip
Headset
Zero Stack Headset w/15mm spacer
Seat
Saddle
Norco MTB Women's Sport - Black
Seatpost
Alloy - Black 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD |
|---|---|---|---|---|
| Stack Reach Ratio | 1.7 mm | 1.65 mm | 1.6 mm | 1.56 mm |
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm | 291 mm |
| Front Center | 611 mm | 626 mm | 642 mm | 658 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 81 mm | 78 mm | 75 mm | 72 mm |
| Stack | 608 mm | 619 mm | 629 mm | 640 mm |
| Reach | 357 mm | 375 mm | 392 mm | 409 mm |
| Top Tube Length | 526 mm | 551 mm | 576 mm | 601 mm |
| Seat Tube Angle | 74.5 ° | 74.1 ° | 73.7 ° | 73.3 ° |
| Seat Tube Length | 350 mm | 390 mm | 430 mm | 470 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70.5 ° | 71 ° |
| Head Tube Length | 100 mm | 107.5 mm | 115 mm | 130 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1058 mm | 1074 mm | 1089 mm | 1107 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 63 mm |
| Standover Height | 690 mm | 673 mm | 661 mm | 659 mm |
| Front Travel | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 145 cm | 157 cm | 165 cm | 174 cm |
| Rider Max Height | 159 cm | 168 cm | 176 cm | 183 cm |
About this model
XFR 5 Step-Thru belongs to the Norco Xfr model. Norco launched 76 bikes of this model so far. You can easily view all of the Norco Xfr bikes models from 2018, here.
Model range prices
Norco XFR 5 Step-Thru 2018 is the cheapest bike model and costs 399$. Norco XFR 1 2018 is the most expensive one and costs 999$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Hybrid bikes
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2018 for 399$. Comparing this to the average Hybrid bike price, we see that the price is 40.85% smaller.
XFR 5 Step-Thru components
Fork
The XFR 5 Step-Thru comes factory-installed with the SunTour fork. This has a travel range of 75mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When it comes to wheels, the XFR 5 Step-Thru bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The XFR 5 Step-Thru has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
This bike is available in 4 sizes. They vary from 145 cm – 183 cm (4.76 ft – 6 ft). In conclusion, finding one for you shouldn’t be a problem.
