Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 80mm -
Fork SunTour XCT
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 168cm
MD
166cm - 176cm
LG
174cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
X6 Aluminum, Smooth Welds
Suspension Fork
SR Suntour XCT30, 80mm, Lockout
Drivetrain
Rear Derailleur
Shimano Deore, Clutch
Shift Levers
Shimano Deore
Cassette
Shimano CS-M4100, 11-46T, 10 Speed
Crank
Forged Aluminum, 38T, 170mm (XS, S, M), 175mm (L, XL)
Bottom Bracket
Cartridge Bearing, BSA Threaded
Chain
KMC X10
Pedals
City, Black
Wheels
Front Hub
Alloy, Weather Sealed, 9x100mm, 6-bolt
Rear Hub
Alloy, Weather Sealed, 10x135mm, HG, 6-bolt
Rims
WTB SX19 Double Wall, 29", 32H
Tires
Kenda 700x50c Fast Rolling
Brakes
Brakes
Tektro HD-M275 Hydraulic Disc
Brake Levers
Tektro HD-M275 Hydraulic
Disk Rotors
Tektro 160mm
Cockpit
Stem
Aluminum, 60mm Reach, 31.8mm Clamp
Handlebar
Aluminum, 660mm (XS), 680mm (S, M) 700mm (L, XL), 25mm Rise
Grips
Norco
Headset
Zero-Stack Internal
Seat
Saddle
Norco Sport
Seatpost
Aluminum, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.68 mm | 1.61 mm | 1.54 mm | 1.49 mm |
| Bottom Bracket Height | 300 mm | 300 mm | 300 mm | 300 mm |
| Front Center | 650 | 680 mm | 711 mm | 741 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 92 mm | 92 mm | 92 mm | 92 mm |
| Stack | 630 mm | 644 mm | 658 mm | 672 mm |
| Reach | 376 mm | 401 mm | 426 mm | 451 mm |
| Top Tube Length | 558 mm | 587 mm | 616 mm | 645 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 125 mm | 140 mm | 155 mm | 170 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1088 mm | 1118 mm | 1149 mm | 1179 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 646 mm | 664 mm | 700 | 732 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 166 cm | 174 cm | 181 cm |
| Rider Max Height | 168 cm | 176 cm | 184 cm | 191 cm |
About this model
XFR 1 completes the Norco Xfr model. Norco launched 76 bikes of this model so far. You can easily view all of the Norco Xfr bikes models from 2021, here.
Model range prices
The most economical model, the Norco XFR 3 Step-Thru 2021 has a starting price of 679$. Norco XFR 1 2021 on the other hand is the most expensive at 879$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid bikes average price
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2021 and its price was 879$. Comparing the average cost of a Hybrid bike to this one, you will see that XFR 1 price is 56.41% more expensive.
Overview of components
Fork
Norco XFR 1 2021 bike is equipped with the SunTour XCT fork, and has 80mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When it comes to wheels, the XFR 1 bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 191 cm (5.18 ft – 6.27 ft). In conclusion, it won’t take much to find one that’s right for you.
