Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork SunTour NRX D
-
Groupset X5, Acera -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
XFR Double Butted 7005 w/Chainstay Disc
Suspension Fork
SR Suntour NRX-D 75mm w/lock-out
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X5 - Black
Front Derailleur
Shimano Acera FD-M390
Shift Levers
Shift housing - Black
Cassette
SRAM PG-950 11-32T 9 speed
Crank
SRAM S650 3.0 Power Spline 48/36/26 - Black
Bottom Bracket
SRAM Power Spline Cartridge BB
Chain
SRAM CN-PC951 9speed
Chain Tensioner
N/A
Pedals
Alloy pedal - Black
Wheels
Front Hub
Formula DC-20 disc - Black
Rear Hub
Shimano Deore FH-M475 black 32h
Rims
Double wall alloy 700c x 32hole - Black
Tires
Norco X-Over 700x42c
Brakes
Brakes
Avid Elixir 1 w/160mm rotors - Black
Brake Levers
Avid Elixir 1 hydraulic disc levers
Disk Rotors
N/A
Cockpit
Stem
Norco - Black w/Orange
Handlebar
Norco 25mm Riser - Black w/Orange
Grips
Norco Gradient Dual Density - Black/Orange
Headset
FSA ZS-4D ACB Cartridge w/13mm spacer
Seat
Saddle
Norco Urban - Black
Seatpost
Norco - Black w/Orange
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | - | - | - | - | - |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.63 mm | 1.62 mm | 1.6 mm | 1.57 mm |
| Bottom Bracket Height | 299 mm | 299 mm | 299 mm | 299 mm | 299 mm |
| Front Center | 619 mm | 628 mm | 637 mm | 651 mm | 665 mm |
| Rake | 38 mm | 38 mm | 37 mm | 37 mm | 38 mm |
| Trail | 87 mm | 83 mm | 81 mm | 81 mm | 77 mm |
| Stack | 615 mm | 626 mm | 638 mm | 647 mm | 659 mm |
| Reach | 372 mm | 383 mm | 394 mm | 405 mm | 421 mm |
| Top Tube Length | 549 mm | 569 mm | 589 mm | 609 mm | 629 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 365 mm | 412 mm | 459 mm | 510 mm | 562 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1061 mm | 1070 mm | 1079 mm | 1093 mm | 1108 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
XFR 2 is a Norco Xfr model. There are 76 bikes that carry this model name. Take a sneak peek at all Norco Xfr bikes models from 2013, by clicking here.
Model range prices
The most economical model, the Norco XFR 3 Forma 2013 has a starting price of 705$. Norco XFR 1 2013 on the other hand is the most expensive at 1165$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid bikes average price
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Norco released this model in 2013, its price was 945$. Comparing the average cost of a Hybrid bike to this one, you will see that XFR 2 price is 68.15% higher.
Overview of components
Fork
The XFR 2 comes factory-installed with the SunTour NRX D fork. This has a travel range of 75mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The wheels on XFR 2 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco XFR 2 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
