Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork SunTour
-
Groupset X4, Altus -
Suspension Hardtail -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
XFR Double Butted 7005 w/Chainstay Disc
Suspension Fork
SR Suntour NVX 75mm w/lock-out
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X4 - Black
Front Derailleur
Shimano Altus FD-M191
Shift Levers
Shift housing - Grey
Cassette
SRAM PG-820 11-32
Crank
SRAM S650 3.0 48/38/28 - Black
Bottom Bracket
SRAM Cartridge BB
Chain
KMC Z-72
Chain Tensioner
N/A
Pedals
Alloy pedal - Black
Wheels
Front Hub
SRAM 306 Disc Hubs - 32h - Black
Rear Hub
SRAM 306 Disc Hubs - 32h - Black
Rims
Double wall alloy 700c x 32hole - Black
Tires
Norco X-Over 700x42c
Brakes
Brakes
Avid DB-1 Hydraulic Discs w/160mm Rotor
Brake Levers
Avid DB-1 Hydraulic Discs
Disk Rotors
N/A
Cockpit
Stem
Norco - Black w/Grey
Handlebar
Norco 25mm Riser - Black w/Grey
Grips
X-Over Dual Density - Black/Grey
Headset
FSA No.11N Semi-cartridge w/20mm spacer
Seat
Saddle
Norco Urban - Black
Seatpost
Norco Alloy 31.6mm - Black w/Grey
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14.5" | 16" | 18" | 20" | 22" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.63 mm | 1.62 mm | 1.6 mm | 1.57 mm |
| Bottom Bracket Height | 299 mm | 299 mm | 299 mm | 299 mm | 299 mm |
| Front Center | 619 mm | 628 mm | 637 mm | 651 mm | 665 mm |
| Rake | 38 mm | 38 mm | 37 mm | 37 mm | 38 mm |
| Trail | 87 mm | 83 mm | 81 mm | 81 mm | 77 mm |
| Stack | 615 mm | 626 mm | 638 mm | 647 mm | 659 mm |
| Reach | 372 mm | 383 mm | 394 mm | 405 mm | 421 mm |
| Top Tube Length | 549 mm | 569 mm | 589 mm | 609 mm | 629 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 365 mm | 412 mm | 459 mm | 510 mm | 562 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1061 mm | 1070 mm | 1079 mm | 1093 mm | 1108 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 732 mm | 779 mm | 800 mm | 824 mm | 853 mm |
| Front Travel | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
XFR 3 is part of the Norco Xfr model. 76 bikes variations carry this model name so far. You can get a glimpse at all models from 2014, by clicking on this link.
Model range prices
The most economical model, the Norco XFR 3 Forma 2014 has a starting price of 675$. Norco XFR 1 2014 on the other hand is the most expensive at 1099$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Hybrid bikes
If you want an acceptable Hybrid bike you should know that the average price is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2014 and its price was 675$. In conclusion, this bike price is 20.11% higher than the price of the average Hybrid bike.
Overview of components
Fork
This bike has the SunTour fork installed. The fork’s travel is 75mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The wheels on XFR 3 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco XFR 3 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
