Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Apex, FSA -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
NS AL6061-T6 custom formed and butted tubes, tapered integrated headtube, 142x12mm dropouts
Suspension Fork
NS Gravel+ full carbon fork, 15mm dropouts, 1.5 tapered steerer tube, NS thru axle
Drivetrain
Rear Derailleur
SRAM Apex Type 2.1, long cage, 11spd
Shift Levers
SRAM Apex, 11spd
Cassette
Microshift CS-G113 11-42t
Crank
FSA Omega S:170mm, M:172.5mm, L:175mm 42t
Chain
SRAM, 11 spd
Pedals
/
Wheels
Front Hub
NS Bikes 100x15mm (loose ball)
Rear Hub
NS Bikes 142x12mm (loose ball)
Rims
Alex Draw 2.1P asymmetrical, 29” 32h, tubeless ready
Spokes
Spokes w/14mm nipples
Tires
r Tufo Gravel Thundero 622-40
Brakes
Brakes
Front: Rever MCX 160mm, Rear: Rever MCX 160mm
Cockpit
Stem
RAG+ Stem 31.8 S:80mm, M:90mm, L:100mm, XL:110mm, angle, - 8°
Handlebar
NS Flare 31.8 420mm (S,M), 440 (L, XL)mm
Grips
Selle Italia SMOOTAPE Gran Fondo
Headset
GW integrated tapered IS42/IS52, sealed bearings
Seat
Saddle
Selle Italia X3
Seatpost
Kalloy 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.46 mm | 1.47 mm | 1.5 mm |
| Bottom Bracket Height | 419 mm | 420 mm | 420 mm | 419 mm |
| Front Center | 609 mm | 615 mm | 636 mm | 656 mm |
| Rake | 2 mm | -3 mm | -2 mm | -1 mm |
| Trail | 128 mm | 127 mm | 126 mm | 125 mm |
| Stack | 533 mm | 576 mm | 599 mm | 627 mm |
| Reach | 386 mm | 394 mm | 407 mm | 417 mm |
| Top Tube Length | 552 mm | 567 mm | 588 mm | 606 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 475 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 69.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 125 mm | 145 mm | 170 mm | 200 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1033 mm | 1040 mm | 1062 mm | 1082 mm |
| Bottom Bracket Drop | -70 mm | -71 mm | -71 mm | -70 mm |
| Standover Height | 763 mm | 792 mm | 825 mm | 853 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Rag + 2 is part of the Ns Rag model. NS launched 6 bikes of this model so far. Take a sneak peek at all Ns Rag bikes models from 2023, by clicking here.
Model range prices
NS Rag JR 2023 is the cheapest bike model and costs 1379$. NS Rag +1 2023 is the most expensive one and costs 2441$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2023 for 1846$. Doing a quick comparison, we notice that Rag + 2 price is 33.37% lower than the average cost of a Gravel bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, NS Rag + 2 2023, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. NS Rag + 2 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
