Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c / 650b -
Groupset 105, FSA -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
XS
156cm - 166cm
SM
163cm - 174cm
SM
163cm - 174cm
MD
171cm - 182cm
MD
171cm - 182cm
LG
179cm - 189cm
LG
179cm - 189cm
XL
185cm - 195cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
Boundary Carbon, Multiple Rack/Fender/Cargo Mounts
Drivetrain
Rear Derailleur
Shimano 105 R7000
Front Derailleur
Shimano 105 R7000
Shift Levers
Shimano R7020
Cassette
Shimano HG700 11-34
Crank
FSA Gossamer Pro 386EVO 48/32
Bottom Bracket
FSA
Chain
Shimano HG601
Wheels
Rims
Select Wheels Above
Tires
Panaracer Gravel King SK 700x43c Tubeless
Brakes
Brakes
Shimano 105
Disk Rotors
Shimano RT66 160mm
Cockpit
Stem
Easton EA50 31.8
Handlebar
Easton EA50 AX 31.8
Headset
Cane Creek 40 Series
Seat
Saddle
WTB Volt Medium Steel
Seatpost
Easton EA50 Zero Setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | XS | SM | SM | MD | MD | LG | LG | XL | XL |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.44 mm | 1.48 mm | 1.48 mm | 1.5 mm | 1.5 mm | 1.53 mm | 1.53 mm | 1.54 mm | 1.54 mm |
| Bottom Bracket Height | 282 mm | mm | 282 mm | mm | 282 mm | mm | 282 mm | mm | 282 mm | mm |
| Front Center | 594 mm | 594 mm | 595 mm | 595 mm | 600 mm | 600 mm | 611 mm | 611 mm | 626 mm | 626 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 64 mm | 73 mm | 66 mm | 64 mm | 58 mm | 61 mm | 55 mm | 61 mm | 55 mm |
| Stack | 542 mm | 542 mm | 562 mm | 562 mm | 573 mm | 573 mm | 595 mm | 595 mm | 614 mm | 614 mm |
| Reach | 376 mm | 376 mm | 380 mm | 380 mm | 381 mm | 381 mm | 390 mm | 390 mm | 399 mm | 399 mm |
| Top Tube Length | 525 mm | 525 mm | 540 mm | 540 mm | 555 mm | 555 mm | 570 mm | 570 mm | 585 mm | 585 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 490 mm | 520 mm | 520 mm | 540 mm | 540 mm | 560 mm | 560 mm | 580 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 120 mm | 120 mm | 140 mm | 140 mm | 150 mm | 150 mm | 170 mm | 170 mm | 190 mm | 190 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1025 mm | 1025 mm | 1026 mm | 1026 mm | 1031 mm | 1031 mm | 1042 mm | 1042 mm | 1057 mm | 1057 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 764 mm | 764 mm | 791 mm | 791 mm | 808 mm | 808 mm | 828 mm | 828 mm | 848 mm | 848 mm |
| Wheels | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 | 700 | 650 |
| Rider Min Height | 156 cm | 156 cm | 163 cm | 163 cm | 171 cm | 171 cm | 179 cm | 179 cm | 185 cm | 185 cm |
| Rider Max Height | 166 cm | 166 cm | 174 cm | 174 cm | 182 cm | 182 cm | 189 cm | 189 cm | 195 cm | 195 cm |
About this model
Boundary 105 is an Ocoee Boundary model. Ocoee launched 8 bikes of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
The most economical model, the Ocoee Boundary GRX 400 2020 has a starting price of 2399$. Ocoee Boundary GRX 810 Di2 2020 on the other hand is the most expensive at 4050$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Ocoee released this model in 2020, its price was 2599$. If we compare this with the average Gravel bike cost we notice that the price is 5.56% more expensive.
Boundary 105 components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The Boundary 105 2020 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Boundary 105 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Ocoee Boundary 105 bike has 10 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
