Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Groupset GX Eagle -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Flat out fast carbon XC hardtail for alloy money. 1200g Toray T700 carbon fibre frame. Race responsive 69.5º head angle geometry. Dropper post, double bottle and 29x2.3 or 27.5x2.8in tyre compatible.
Suspension Fork
Selcof Carbon 27.5+ or 29er Fork / Matt Black
Drivetrain
Rear Derailleur
SRAM GX Eagle Rear Mech / 1 x 12 Speed
Cassette
Shimano SLX M7100 12 Speed Micro Spline Cassette / 10-51 Tooth
Crank
SRAM GX Eagle DUB Crankset / 170mm / 32 Tooth / BOOST
Bottom Bracket
SRAM DUB BSA Bottom Bracket / 73mm
Chain
SRAM SX Eagle 12 Speed Chain / 126 Link
Wheels
Rims
Shimano MT501 29er Boost Centrelock Wheelset / Shimano Microspline 12 Speed
Tires
Panaracer FireSport 29" Wire Bead Tyre / 2.35"
Brakes
Brakes
SRAM Guide R Hydraulic Disc Brake / Rear / 1600mm / 20 Post to IS
Cockpit
Stem
On-One Hot Box V2 Stem / 60mm / 7 Degree / 31.8mm
Handlebar
Controltech LYNX Alloy Riser Bar / 800mm / Red/White
Grips
On-One Half Bob Lock-On Foam Grips / Black
Seat
Saddle
San Marco Monza Start Saddle / Black / Carbon Steel
Seatpost
On-One Twelfty V2 6061 Alloy Seatpost / 31.6mm / 400mm / Black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | 19" | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.44 mm | 1.41 mm | 1.37 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 659 mm | 684 mm | 710 mm | 736 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 101 mm | 90 mm | 89 mm | 87 mm |
| Stack | 602 mm | 605 mm | 620 mm | 630 mm |
| Reach | 407 mm | 420 mm | 440 mm | 460 mm |
| Top Tube Length | 570 mm | 595 mm | 620 mm | 645 mm |
| Seat Tube Angle | 73.7 ° | 73.7 ° | 74.7 ° | 73.7 ° |
| Seat Tube Length | 395 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 95 mm | 100 mm | 115 mm | 125 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1082 mm | 1107 mm | 1133 mm | 1159 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
Whippet SRAM GX is an Onone Whippet model. On-One released 13 bikes variations of this model so far. Take a sneak peek at all Onone Whippet bikes models from 2020, by clicking here.
Model range prices
On-One Whippet SRAM SX 2020 is the most affordable bike of this model and has a price of 1215$. On the other hand, On-One Whippet Shimano SLX 2020, is the most expensive and costs 1823$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1702$. Doing a quick comparison, we notice that Whippet SRAM GX price is 11.93% smaller than the average cost of a Crosscountry bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When leaving the production line, the Whippet SRAM GX model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Whippet SRAM GX comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
