Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 155mm -
Fork RockShox Lyrik Ultimate
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Lyrik Ultimate, 37mm offset
Rear Shock
RockShox Super Deluxe Ultimate, 230mm x 65mm
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed
Front Derailleur
None
Shift Levers
Shimano Deore XT M8100, 12-speed
Cassette
Shimano Deore XT M8100, 12-speed, 10-51 tooth
Crank
Hope Tech
Bottom Bracket
Hope Tech, 73mm
Chain
KMC, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Hope Tech Pro 4, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPLINE driver
Rear Hub
Hope Tech Pro 4, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPLINE driver
Rims
e*thirteen TRS, 30mm width
Tires
Front: Maxxis Minion DHF, 3C, EXO, 27.5" x 2.5", Rear: Maxxis Minion DHR II, EXO, 27.5" x 2.4"
Brakes
Brakes
Shimano Deore XT Trail M8120, 4-piston, 203mm front rotor, 180mm rear rotor
Brake Levers
Shimano Deore XT Trail M8120
Cockpit
Stem
Hope Tech, 35mm length, 35mm bar clamp
Handlebar
Renthal Fatbar, 800mm width, 35mm clamp diameter
Grips
Strange Grappler, lock-on
Headset
Cane Creek, ZS49/28.6 upper, EC49/40 lower
Seat
Saddle
SDG Strange BelAir III
Seatpost
SDG Tellis dropper, 150mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.29 mm | 1.26 mm | 1.23 mm | 1.19 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm | 337 mm |
| Front Center | 792 mm | 814 mm | 835 mm | 856 mm |
| Rake | 37 mm | 37 mm | 35 mm | 36 mm |
| Trail | 140 mm | 140 mm | 142 mm | 141 mm |
| Stack | 587 mm | 596 mm | 605 mm | 609 mm |
| Reach | 456 mm | 474 mm | 493 mm | 511 mm |
| Top Tube Length | 603 mm | 623 mm | 643 mm | 663 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 381 mm | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 63 ° | 63 ° | 63 ° | 63 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 125 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1234 mm | 1256 mm | 1278 mm | 1299 mm |
| Bottom Bracket Drop | 17 mm | 17 mm | 17 mm | 17 mm |
| Standover Height | 718 mm | 740 mm | 770 mm | 793 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Alpine EVO LE completes the Orange Alpine model. Orange released 24 bikes variations of this model so far. You can easily view all of the Orange Alpine bikes models from 2022, here.
Model range prices
Orange Alpine 6 Pro-Line 2022 is the cheapest bike model and costs 7200$. Orange Alpine EVO SE 2022 is the most expensive one and costs 7600$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro bikes
According to our calculations, the average cost of an Enduro bike that is reliable is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork
Orange Alpine EVO LE 2022 bike is equipped with the RockShox Lyrik Ultimate fork, and has 160mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The Alpine EVO LE has a rear shock with a travel of 155mm. The model RockShox Super Deluxe Ultimate is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The wheels on Alpine EVO LE are the 27.5″ aluminum type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orange Alpine EVO LE is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Orange Alpine EVO LE comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
