Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox Lyrik Ultimate
-
Groupset GX Eagle, Shimano -
Suspension Full -
Motor Shimano mid-drive -
Battery Shimano E806 630wh Integrated battery Gen 2 -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Monocoque UK Formed Custom Aluminium Tubing. Wheel Size: 27.5. Rear wheel travel: 145.
Suspension Fork
RockShox Lyrik Ultimate 160mm
Rear Shock
RockShox Super Deluxe Ultimate 230x57.5
Drivetrain
Rear Derailleur
SRAM GX Eagle 12spd
Shift Levers
SRAM GX Eagle - Single Click
Cassette
SRAM XG 1275 10-52t Eagle
Crank
Shimano M600 165 E 34t
Bottom Bracket
Shimano EP8 DU Integrated
Chain
SRAM NX Eagle
Wheels
Rims
E13 LG1 EN 30mm (Grey) + Hope Pro 4 (Black) 27.5
Tires
Maxxis Minion DHF 2.5 3c EXO+ / DHR II 2.4 3c EXO+ 27.5
Brakes
Brakes
SRAM Guide RE 200/200
Cockpit
Stem
Burgtec Enduro Black 42.5mm
Handlebar
Burgtec RideWide Enduro 800mm
Grips
Strange Grappler Lock-On
Headset
Acros 49mm Blocklock for Tapered Steerer
Seat
Saddle
SDG Strange Bel Air III
Seatpost
SDG Tellis 150/170mm
Motor & Battery
Motor
Shimano EP801
Battery
Shimano E806 630wh Integrated battery Gen 2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.28 mm | 1.24 mm | 1.21 mm | 1.19 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm | 334 mm |
| Front Center | 808 mm | 828 mm | 850 mm | 873 mm |
| Rake | 37 mm | 38 mm | 38 mm | 38 mm |
| Trail | 132 mm | 131 mm | 131 mm | 131 mm |
| Stack | 620 mm | 620 mm | 629 mm | 638 mm |
| Reach | 483 mm | 502 mm | 520 mm | 538 mm |
| Top Tube Length | 626 mm | 646 mm | 666 mm | 686 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 406 mm | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1254 mm | 1274 mm | 1296 mm | 1319 mm |
| Bottom Bracket Drop | 21 mm | 21 mm | 21 mm | 21 mm |
| Standover Height | 726 mm | 740 mm | 754 mm | 780 mm |
| Rear Travel | 150 mm | 150 mm | 150 mm | 150 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Charger RS is an Orange E Charger model. 11 e-bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Orange Charger S 2023 is the most economical model, with a starting price of 8365$. Orange Charger Factory 2023 on the other hand costs 10801$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro e-bikes
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
When Orange released this model in 2023, its price was 9848$. In conclusion, this e-bike price is 105.81% more expensive than the price of the average Enduro e-bike.
Charger RS components
Fork
The fork installed on this bike is the RockShox Lyrik Ultimate model. The travel on this model is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the RockShox Super Deluxe Ultimate 230×57.5 rear shock model, which has a travel of 150mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The wheels on Charger RS are the 27.5″ aluminum type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Charger RS comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Orange Charger RS includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
