Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Fork RockShox Judy Silver TK
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Custom Butted OS Aluminium Tube. Wheel Size: 27.5.
Suspension Fork
RockShox Judy Silver TK 130mm 27.5
Drivetrain
Rear Derailleur
Shimano Deore 11spd
Shift Levers
Shimano Deore 11spd
Cassette
Sunrace CSMS7 11-51t 11spd
Crank
Strange Prowheel Charm 170mm Narrow Wide 32t
Bottom Bracket
Prowheel
Chain
KMC 11spd
Wheels
Rims
Alex VED7B 27.5
Tires
Maxxis dissector 2.4 27.5
Brakes
Brakes
Clarks Clout 180/160
Cockpit
Stem
Strange Stalk 40mm
Handlebar
Strange 1" Rise 780mm
Grips
Strange Grappler Lock-On
Headset
FPD 44mm For Tapered Steerer
Seat
Saddle
WTB Volt Steel
Seatpost
Strange Post 400 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.4 mm | 1.36 mm | 1.32 mm |
| Bottom Bracket Height | 407 mm | 407 mm | 407 mm | 407 mm |
| Front Center | 722 mm | 756 mm | 780 mm | 804 mm |
| Trail | 158 mm | 158 mm | 158 mm | 158 mm |
| Stack | 630 mm | 639 mm | 648 mm | 657 mm |
| Reach | 427 mm | 457 mm | 477 mm | 497 mm |
| Top Tube Length | 605 mm | 638 mm | 661 mm | 683 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 356 mm | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1151 mm | 1185 mm | 1209 mm | 1233 mm |
| Bottom Bracket Drop | -52 mm | -52 mm | -52 mm | -52 mm |
| Standover Height | 665 mm | 683 mm | 701 mm | 737 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Clockwork comp is an Orange Clockwork model. Orange launched 18 bikes of this model so far. You can easily view all of the Orange Clockwork bikes models from 2023, here.
Model range prices
The most economical model, the Orange Clockwork 29 2023 has a starting price of 2224$. Orange Clockwork 29 comp 2023 on the other hand is the most expensive at 2436$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2436$. Doing a quick comparison, we notice that Clockwork comp price is 13.38% smaller than the average cost of a Trail bike.
Overview of components
Fork
The Clockwork comp comes factory-installed with the RockShox Judy Silver TK fork. This has a travel range of 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The Clockwork comp 2023 bike is equipped with 27.5″ aluminum wheels when leaving the factory. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Orange Clockwork comp has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Clockwork comp comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
