Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox Pike Ultimate
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Pike Ultimate, 37mm offset
Rear Shock
RockShox Super Deluxe Ultimate, 190mm x 45mm
Drivetrain
Rear Derailleur
Shimano XT 12-speed
Front Derailleur
None
Shift Levers
Shimano XT 12-speed
Cassette
Shimano XT 10-51 tooth 12-speed
Crank
Hope Tech (silver)
Bottom Bracket
Hope Tech, 30mm (silver)
Chain
Shimano XT 12-speed
Chain Guide
None
Pedals
None included
Wheels
Front Hub
Hope Tech Pro 4 (silver)
Rear Hub
Hope Tech Pro 4 (silver)
Rims
e*thirteen TRS, 30mm inner width
Tires
Front: Maxxis Minion DHF 27.5"x2.5" WT, Rear: Maxxis Minion DHR II 27.5"x2.4" WT
Brakes
Brakes
Hope Tech 3 E4 (silver/black), 203mm/180mm rotors
Brake Levers
Hope Tech 3 E4 (silver/black)
Cockpit
Stem
Burgtec MK3 Enduro (silver), 42.5mm length
Handlebar
Burgtec RideWide Enduro, 800mm width
Grips
Orange Strange 130, single lock-on, 130mm length
Headset
Hope Tech (silver), 49mm for tapered steerer
Seat
Saddle
SDG Radar, cromo rail
Seatpost
SDG Tellis, 150mm travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.3 mm | 1.24 mm | 1.24 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm | 320 mm |
| Stack | 592 mm | 601 mm | 601 mm | 619 mm |
| Reach | 445 mm | 462 mm | 483 mm | 498 mm |
| Top Tube Length | 593 mm | 613 mm | 633 mm | 653 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 381 mm | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 110 mm | 110 mm | 130 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1194 mm | 1216 mm | 1236 mm | 1260 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 690 mm | 710 mm | 728 mm | 755 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Five Evo LE is part of the Orange Five model. Orange released 23 bikes variations of this model so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Orange Five EVO S 2021 is the most affordable bike of this model and has a price of 3600$. On the other hand, Orange Five EVO XTR 2021, is the most expensive and costs 6800$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Five Evo LE components
Fork
The RockShox Pike Ultimate is included from the factory. It has a travel distance of 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this bike has the RockShox Super Deluxe Ultimate model, with a travel of 130mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the Five Evo LE bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orange Five Evo LE is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Five Evo LE comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Orange Five Evo LE comes with a dropper post. Therefore, climbing or descending will be a breeze.
