Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 140mm -
Fork Fox Performance Float 36
-
Groupset GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Chromoly
Suspension Fork
FOX FLOAT 36 Performance, 46mm offset
Rear Shock
None
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed
Front Derailleur
None
Shift Levers
SRAM GX Eagle, 12-speed
Cassette
SRAM SX Eagle PG-1210, 12-speed, 11-50 tooth
Crank
SRAM GX Eagle DUB
Bottom Bracket
SRAM DUB, 73mm
Chain
SRAM GX Eagle, 12-speed
Chain Guide
None, Option: OneUp upper slider
Pedals
None, Option: Burgtec Penthouse Flat MK5
Wheels
Front Hub
Hope Tech Pro 4, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rear Hub
Hope Tech Pro 4, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rims
e*thirteen TRS, 30mm width, Option: Stan's NoTubes Flow MK3
Tires
Front: Maxxis Minion DHF, 3C, EXO, 29" x 2.6", Rear: Maxxis Minion DHR II, EXO, 29" x 2.4"
Brakes
Brakes
SRAM Guide RE, 4-piston, 200mm front rotor, 180mm rear rotor, Option: Shimano Deore XT Trail, 4-piston, 203mm front rotor, 180mm rear rotor, Option: Shimano SLX Trail, 4-piston, 203mm front rotor, 180mm rear rotor
Brake Levers
SRAM Guide RE, Option: Shimano Deore XT Trail, Option: Shimano SLX Trail
Cockpit
Stem
Burgtec Enduro, 42.5mm length
Handlebar
Burgtec RideWide Enduro, 800mm width
Grips
Strange Grappler, lock-on
Headset
FPD, ZS44/28.6 upper, EC44/40 lower
Seat
Saddle
SDG Radar, steel rails
Seatpost
FOX Transfer Performance Elite dropper, 175mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.43 mm | 1.36 mm |
| Bottom Bracket Height | 302 mm | 302 mm | 302 mm |
| Stack | 644 mm | 653 mm | 662 mm |
| Reach | 435 mm | 458 mm | 485 mm |
| Top Tube Length | 620 mm | 647 mm | 676 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1200 mm | 1228 mm | 1259 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm |
| Standover Height | 690 mm | 708 mm | 749 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
P7 29 R is part of the Orange P7 model. Orange launched 18 bikes of this model so far. You can easily view all of the Orange P7 bikes models from 2021, here.
Model range prices
The most economical model, the Orange P7 29 S 2021 has a starting price of 2600$. Orange P7 R 2021 on the other hand is the most expensive at 3700$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Orange P7 29 R price was 3700$. Comparing the average cost of a Trail bike to this one, you will see that P7 29 R price is 33.96% higher.
Overview of components
Fork
The Fox Performance Float 36 is included from the factory. It has a travel distance of 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The wheels on P7 29 R are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Orange P7 29 R has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Orange P7 29 R bike has 3 sizes, in the range of 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
