Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 400, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Custom Butted OS Aluminium Tube. Wheel Size: 700c.
Suspension Fork
Strange Carbon With Alloy Steerer
Drivetrain
Rear Derailleur
Shimano GRX RX400
Shift Levers
Shimano GRX RX400
Cassette
Shimano Tiagra 11-34T
Crank
FSA Omega 46x30t
Bottom Bracket
Shimano Hollow Tech II
Chain
KMC 10spd
Wheels
Rims
WTB ST i21 on Strange 700
Brakes
Brakes
Shimano GRX RX400 Hydraulic Disc
Cockpit
Grips
Strange EAV Gel Bar Tape Black
Headset
FPD 44mm / 56mm zerostack
Seat
Saddle
WTB Volt Steel
Seatpost
Strange Post 400 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.481 mm | 1.46 mm | 1.471 mm | 1.481 mm |
| Bottom Bracket Height | 406 mm | 406 mm | 406 mm | 406 mm |
| Front Center | 596 mm | 616 mm | 633 mm | 649 mm |
| Rake | -3 mm | -3 mm | -3 mm | -3 mm |
| Trail | 127 mm | 127 mm | 127 mm | 127 mm |
| Stack | 548 mm | 562 mm | 581 mm | 600 mm |
| Reach | 370 mm | 385 mm | 395 mm | 405 mm |
| Top Tube Length | 527 mm | 546 mm | 562 mm | 577 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 125 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1021 mm | 1041 mm | 1058 mm | 1075 mm |
| Bottom Bracket Drop | -70 mm | -70 mm | -70 mm | -70 mm |
| Standover Height | 762 mm | 776 mm | 796 mm | 812 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
RX9 S belongs to the Orange Rx9 model. There are 5 bikes that carry this model name. Take a sneak peek at all Orange Rx9 bikes models from 2023, by clicking here.
Model range prices
Orange RX9 S 2023 is the most affordable bike of this model and has a price of 2679$. On the other hand, Orange RX9 RS 2023, is the most expensive and costs 3812$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Endurance bikes
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, this doesn’t mean that if you spend less money on an Endurance bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2023 and its price was 2679$. Comparing this to the average Endurance bike price, we see that the price is 14.19% higher.
RX9 S components
Fork material
RX9 S has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The RX9 S 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orange RX9 S is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
