Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork Öhlins RXF36
-
Groupset SLX, GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Monocoque UK Formed Custom Aluminium Tubing. Wheel Size: 29. Rear wheel travel: 140.
Suspension Fork
Ohlins RXF 36 M.2 Air 150mm 29
Rear Shock
Ohlins TTX1 Air 210x55
Drivetrain
Rear Derailleur
Shimano SLX 12spd
Shift Levers
Shimano SLX 12spd
Cassette
Shimano SLX 10-51T 12spd
Crank
SRAM GX Eagle 32t
Bottom Bracket
SRAM DUB
Chain
KMC 12spd
Wheels
Rims
E13 LG1 EN 30mm (Grey) + Hope Pro 4 (Black) 29
Tires
Maxxis Minion DHF 2.5 3C Exo / DHR II 2.4 Exo 29
Brakes
Brakes
SRAM Guide RE 200/180
Cockpit
Stem
Burgtec Enduro Black 42.5mm
Handlebar
Burgtec RideWide Enduro 800mm
Grips
Strange Grappler Lock-On
Headset
Cane Creek 49mm for Tapered Steerer
Seat
Saddle
SDG Strange Bel Air III
Seatpost
SDG Tellis 150/170mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.29 mm | 1.27 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm |
| Front Center | 808 mm | 827 mm | 849 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 129 mm | 129 mm | 130 mm |
| Stack | 628 mm | 628 mm | 638 mm |
| Reach | 466 mm | 485 mm | 503 mm |
| Top Tube Length | 623 mm | 643 mm | 663 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1270 mm | 1289 mm | 1311 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 44 mm |
| Standover Height | 731 mm | 742 mm | 795 mm |
| Rear Travel | 140 mm | 140 mm | 140 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Stage 6 Evo SE belongs to the Orange Stage model. Orange launched 51 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Orange Stage Evo Pro 2023 is the most affordable bike of this model and has a price of 5506$. On the other hand, Orange Stage 6 Evo AXS 2023, is the most expensive and costs 8789$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2023 and its price was 7412$. Comparing this to the average Trail bike price, we see that the price is 168.36% more expensive.
Overview of components
Fork
This bike has the Öhlins RXF36 fork installed. The fork’s travel is 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
As for the rear shock, this bike has the Ohlins TTX1 Air 210×55 model, with a travel of 140mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The wheels on Stage 6 Evo SE are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Stage 6 Evo SE has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
