Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 170mm -
Fork Fox Performance Float 38
-
Groupset SLX, SX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Monocoque UK Formed Custom Aluminium Tubing. Wheel Size: MX - 29/27.5. Rear wheel travel: 170.
Suspension Fork
Fox Performance 38 Float 170mm 29
Rear Shock
Fox Float X Performance 205x65
Drivetrain
Rear Derailleur
Shimano SLX 12spd
Shift Levers
Shimano SLX 12spd
Cassette
Shimano SLX 10-51T 12spd
Crank
SRAM SX Eagle 32t
Bottom Bracket
SRAM DUB
Chain
KMC 12spd
Wheels
Rims
E13 LG1 30mm + Strange Pro 29
Tires
Maxxis Minion DHR II 2.4 EXO 29/ DHR II 2.4 EXO 27.5
Brakes
Brakes
SRAM Guide RE 200/180
Cockpit
Stem
Burgtec Enduro Black 42.5mm
Handlebar
Burgtec RideWide Enduro 800mm
Grips
Strange Grappler Lock-On
Headset
FPD 44mm / 56mm zerostack
Seat
Saddle
WTB Silverado SL
Seatpost
SDG Tellis 150/170mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.36 mm | 1.33 mm | 1.3 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 803 mm | 823 mm | 845 mm | 867 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 151 mm | 138 mm | 140 mm | 140 mm |
| Stack | 642 mm | 642 mm | 652 mm | 660 mm |
| Reach | 464 mm | 472 mm | 490 mm | 508 mm |
| Top Tube Length | 611 mm | 631 mm | 651 mm | 671 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 406 mm | 432 mm | 457 mm | 483 mm |
| Head Tube Angle | 63 ° | 63 ° | 63 ° | 63 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 454 mm | 454 mm | 454 mm | 454 mm |
| Wheelbase | 1256 mm | 1276 mm | 1298 mm | 1320 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 712 mm | 730 mm | 756 mm | 776 mm |
| Rear Travel | 170 mm | 170 mm | 170 mm | 170 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Switch 7 Pro completes the Orange Switch model. Orange launched 16 bikes of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Orange Switch 7 Pro 2023 is the most affordable bike of this model and has a price of 6883$. On the other hand, Orange Switch 7 Factory 2023, is the most expensive and costs 8789$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro bikes
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Orange released this model in 2023, its price was 6883$. Comparing this to the average Enduro bike price, we see that the price is 91.25% more expensive.
Overview of components
Fork
The Fox Performance Float 38 is included from the factory. It has a travel distance of 170mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this bike is Fox Float X Performance 205×65, with a travel distance of 170mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The Switch 7 Pro 2023 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Orange Switch 7 Pro has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
