Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
47cm
155cm - 161cm
49cm
159cm - 168cm
51cm
165cm - 174cm
53cm
171cm - 181cm
55cm
178cm - 187cm
57cm
184cm - 193cm
60cm
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Avant Hydro disc, hydroformed triple butted aluminium, HS 1,5" ICR, BB 68mm – BSC English, Thru Axle 12x142mm rear, thread M12x2 P1, Internal Cable Routing, SP 27,2mm, MMS system.
Suspension Fork
Orbea carbon fork 2021, aluminum steerer, 1-1/8" head tube
Drivetrain
Rear Derailleur
Shimano Tiagra 4700 GS
Front Derailleur
Shimano Tiagra 4700
Shift Levers
Shimano Tiagra ST-4700
Cassette
Sun Race CSMS1 11-34t 10-Speed
Crank
FSA Omega Megaexo 34x50t
Bottom Bracket
BSA, 68mm, threaded
Chain
KMC X10
Wheels
Rims
Orbea wheel: Cosra with 12mm E-Thru hubset Shimano RS470 28H
Tires
Vittoria Zafiro V Rigid bead 700x28c
Brakes
Brakes
Tektro MD-C550 Mechanical Disc
Cockpit
Stem
OC1 31.8mm interface -6º
Handlebar
OC1 Road, reach 80mm, drop 125mm
Headset
Acros Alloy 1-1/2" Internal Cable Routing
Seat
Saddle
Selle Royal Seta RS
Seatpost
Alloy 27.2 Offset 20
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 51cm | 53cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.47 mm | 1.5 mm | 1.54 mm | 1.55 mm | 1.58 mm | 1.61 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 576 mm | 583 mm | 590 mm | 592 mm | 606 mm | 615 mm | 624 mm |
| Rake | 48 mm | 48 mm | 48 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 66 mm | 63 mm | 60 mm | 62 mm | 61 mm | 61 mm | 60 mm |
| Stack | 528 mm | 548 mm | 568 mm | 588 mm | 608 mm | 628 mm | 648 mm |
| Reach | 368 mm | 373 mm | 378 mm | 383 mm | 393 mm | 398 mm | 403 mm |
| Top Tube Length | 514 mm | 529 mm | 542 mm | 556 mm | 572 mm | 589 mm | 600 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.75 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 445 mm | 470 mm | 495 mm | 520 mm | 545 mm | 575 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.9 ° | 72.4 ° | 72.6 ° | 72.8 ° | 73 ° |
| Head Tube Length | 122 mm | 141 mm | 161 mm | 180 mm | 201 mm | 221 mm | 241 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 992 mm | 999 mm | 1007 mm | 1009 mm | 1023 mm | 1032 mm | 1041 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 73 mm | 73 mm | 73 mm | 73 mm |
| Standover Height | 716 mm | 741 mm | 764 mm | 793 mm | 812 mm | 836 mm | 855 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 159 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 161 cm | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
Model Overview
AVANT H40-D is an Orbea Avant model. There are 41 bikes that carry this model name. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
The most economical model, the Orbea AVANT H50 2021 has a starting price of 1142$. Orbea AVANT H30-D 2021 on the other hand is the most expensive at 1999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Endurance bikes average price
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, this doesn’t mean that if you spend less money on an Endurance bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Orbea AVANT H40-D price was 1699$. If we compare this with the average Endurance bike cost we notice that the price is 38.08% lower.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
AVANT H40-D components
Fork material
AVANT H40-D has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
As for the wheels, Orbea AVANT H40-D 2021, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The AVANT H40-D comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
This bike is available in 7 sizes. They vary from 155 cm – 207 cm (5.09 ft – 6.79 ft). In short, it won’t be difficult to find the right one for you.
