Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
47cm
155cm - 161cm
49cm
159cm - 168cm
51cm
165cm - 174cm
53cm
171cm - 181cm
55cm
178cm - 187cm
57cm
184cm - 193cm
60cm
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Avant carbon OMP disc, monocoque construction,tapered 1-1/8" - 1,5", BB 386mm, powermeter compatible, Thru Axle 12mm x 142mm rear, internal cable routing, EC/DC compatible, 27,2mm seat tube.
Suspension Fork
Avant OMP carbon disc fork, full carbon steerer, tapered 1-1/8" - 1,5", carbon dropouts Thru axle 12mm x 100m
Drivetrain
Rear Derailleur
Shimano 105 R7000 GS
Front Derailleur
Shimano 105 R7000
Shift Levers
Shimano ST-7020
Cassette
Shimano 105 R7000 11-28t 11-Speed Shimano 105 R7000 11-30t 11-Speed Shimano 105 R7000 11-32 11-Speed (RD GS)
Crank
Shimano 105 R7000 34x50t FSA Gossamer Pro 32x48t Shimano 105 R7000 39x53t Rotor Aldhu 36x52t Rotor 2INpower DM 34x50t Rotor 2INpower DM 36x52t
Bottom Bracket
386EVO, 86mm, press-fit
Chain
KMC X11-EL
Pedals
N/A
Wheels
Rims
FULCRUM Racing 600 DB Mavic Ksyrium Elite Black UST DB + Tires Fulcrum Racing Quattro Carbon DB DT Swiss P1850 23 DT Swiss ERC1400 Spline 47
Tires
Vittoria Rubino Foldable 700x25 60TPI G+ Hutchinson Fusion 5 All Season TLR 700x25 Hutchinson Fusion 5 All Season TLR 700x28 Hutchinson Sector 700x28 TLR Hutchinson Sector 700x32 TLR
Brakes
Brakes
Shimano R7070 Hydraulic Disc
Cockpit
Stem
Orbea OC-III FSA Energy FSA OS-99 CSI
Handlebar
FSA Gossamer Compact FSA Energy Compact FSA K-Force Compact Vision Metron 4D Compact
Headset
FSA 1-1/8 - 1-1/2" Integrated Carbon Cup ACB Bearings
Seat
Saddle
Selle Italia X3 Flow Prologo Scratch-2 Tirox size 143 mm Black Prologo Nago Evo Space Tirox size 141mm Prologo Dimension T4,0 Black Selle Italia SLR Kit Carbonio Black
Seatpost
Orbea OC-III Carbon 27.2x350mm FSA K-Force Offset SB0 27,2x350/400mm FSA K-Force Offset SB25 27,2x350/400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 51cm | 53cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.46 mm | 1.5 mm | 1.52 mm | 1.56 mm | 1.58 mm | 1.61 mm |
| Bottom Bracket Height | 270 mm | 270 mm | 270 mm | 272 mm | 272 mm | 272 mm | 272 mm |
| Front Center | 575 mm | 576 mm | 586 mm | 588 mm | 598 mm | 609 mm | 621 mm |
| Rake | 50 mm | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 64 mm | 65 mm | 58 mm | 60 mm | 59 mm | 58 mm | 57 mm |
| Stack | 513 mm | 528 mm | 546 mm | 565 mm | 588 mm | 607 mm | 628 mm |
| Reach | 357 mm | 361 mm | 365 mm | 371 mm | 376 mm | 383 mm | 391 mm |
| Top Tube Length | 501 mm | 513 mm | 526 mm | 540 mm | 552 mm | 571 mm | 585 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.75 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 490 mm | 510 mm | 530 mm | 560 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.9 ° | 72.4 ° | 72.6 ° | 72.8 ° | 73 ° |
| Head Tube Length | 108 mm | 121 mm | 138 mm | 158 mm | 181 mm | 200 mm | 221 mm |
| Chainstay Length | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm |
| Wheelbase | 971 mm | 972 mm | 982 mm | 985 mm | 995 mm | 1006 mm | 1018 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 73 mm | 73 mm | 73 mm | 73 mm |
| Standover Height | 720 mm | 743 mm | 764 mm | 786 mm | 807 mm | 825 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 159 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 161 cm | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
Model Overview
AVANT M30TEAM-D completes the Orbea Avant model. There are 41 bikes that carry this model name. You can easily view all of the Orbea Avant bikes models from 2018, here.
Model range prices
Orbea AVANT H50 2018 is the cheapest bike model and costs 1049$. Orbea AVANT M10iTEAM-D 2018 is the most expensive one and costs 7999$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Endurance bikes average price
If you want to purchase a solid Endurance bike, it is important to know that the average cost is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Orbea AVANT M30TEAM-D price was 2999$. If we compare this with the average Endurance bike cost we notice that the price is 27.83% more expensive.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
AVANT M30TEAM-D components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, Orbea AVANT M30TEAM-D 2018, has a 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea AVANT M30TEAM-D is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Orbea AVANT M30TEAM-D bike has 7 sizes, in the range of 155 cm – 207 cm (5.09 ft – 6.79 ft). In short, you can easily find one that suits you.
