Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Ultegra, Shimano -
Suspension Rigid -
Motor hub-drive -
Battery Ebikemotion 36V/6.9A -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
159cm - 171cm
MD
169cm - 181cm
LG
179cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Gain Hydro, Aluminum 6000 series, Orbea Tube Shaping, Flat Mount Disc Brakes, 135x9 QR, Carrier and Mudguards compatible, max 700x40C, Inner Cable routing, Ebikemotion X35 specific, integrated battery, in
Suspension Fork
Speed 400mm Carbon Flat mount
Drivetrain
Rear Derailleur
Shimano Ultegra R8000 GS
Front Derailleur
Shimano Ultegra R8000
Shift Levers
Shimano ST-8020
Cassette
Shimano Ultegra R8000 11-32t 11-Speed
Crank
Shimano Ultegra R8000 34x50t
Chain
KMC e11 Turbo Silver
Pedals
N/A
Wheels
Rims
Ready GR
Tires
Hutchinson Fusion 5 All Season TLR 700x28
Brakes
Brakes
Shimano R8070 Hydraulic Disc
Cockpit
Stem
FSA Energy
Handlebar
FSA Energy Compact
Headset
1-1/8" Semi-Integrated
Seat
Saddle
Prologo Kappa Space STN size 147mm
Seatpost
FSA SL-K SB20 27.2x350mm Di2 compatible
Motor & Battery
Motor
Ebikemotion X35
Battery
Ebikemotion 36V/6.9A
Charger
Ebikemotion X35
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.44 mm | 1.47 mm | 1.5 mm | 1.53 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 283 mm | 283 mm | 285 mm |
| Front Center | 596 mm | 602 mm | 616 mm | 630 mm | 645 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 63 mm | 57 mm | 58 mm | 59 mm | 55 mm |
| Stack | 527 mm | 547 mm | 567 mm | 592 mm | 617 mm |
| Reach | 370 mm | 379 mm | 387 mm | 394 mm | 402 mm |
| Top Tube Length | 514 mm | 538 mm | 552 mm | 566 mm | 587 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 460 mm | 510 mm | 555 mm | 585 mm | 610 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° | 72.3 ° |
| Head Tube Length | 109 mm | 127 mm | 150 mm | 176 mm | 203 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1008 mm | 1014 mm | 1029 mm | 1043 mm | 1059 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 68 mm | 68 mm | 66 mm |
| Standover Height | 746 mm | 774 mm | 807 mm | 821 mm | 868 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 161 cm | 171 cm | 181 cm | 191 cm | cm |
About this model
GAIN D20 USA is part of the Orbea E Gain model. 78 e-bikes variations carry this model name so far. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Orbea GAIN F30 USA 2019 is the most affordable e-bike of this model and has a price of 2499$. On the other hand, Orbea GAIN M20i USA 2019, is the most expensive and costs 5799$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Endurance e-bikes average price
If you want an acceptable Endurance e-bike you should know that the average price is 3800$. However, even though the average price of an Endurance e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2019 for 3699$. Doing a quick comparison, we notice that GAIN D20 USA price is 2.73% lower than the average cost of an Endurance e-bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
GAIN D20 USA components
Fork material
When it comes to the fork, this e-bike has a carbon one, so, it won’t add up to much weight to your e-bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
As for the wheels, Orbea GAIN D20 USA 2019, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea GAIN D20 USA is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
