Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Fork Marzocchi Bomber Z2
-
Groupset SLX, Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 165cm
MD
160cm - 175cm
LG
170cm - 185cm
XL
180cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Laufey Hydro Triple Butted 29" Boost 12x148 ISCG 05
Suspension Fork
Marzocchi Bomber Z2 140 QR15x110
Drivetrain
Rear Derailleur
Shimano SLX M7100 SGS Shadow Plus
Shift Levers
Shimano Deore M6100 I-Spec EV
Cassette
Sun Race 11-51t 12-Speed
Crank
Shimano MT511 32t
Chain
Shimano M6100
Wheels
Rims
Orbea OC1 29c Tubeless Ready
Tires
Maxxis Rekon 2.60" FB 60 TPI Dual Exo TR
Brakes
Brakes
Shimano M6100 Hydraulic Disc
Cockpit
Stem
OC1 3D Forged 35mm interface 7º
Handlebar
OC1 35mm 12mm Rise 780mm
Headset
FSA 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Royal 2043 HRN
Seatpost
OC2 Dropper 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.46 mm | 1.41 mm | 1.37 mm |
| Bottom Bracket Height | 313.5 mm | 313.5 mm | 313.5 mm | 313.5 mm |
| Front Center | 719 mm | 747 mm | 775 mm | 808 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 122 mm | 122 mm | 122 mm | 122 mm |
| Stack | 630 mm | 634 mm | 643 mm | 662 mm |
| Reach | 407 mm | 433 mm | 457 mm | 482 mm |
| Top Tube Length | 576 mm | 604 mm | 630 mm | 660 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 381 mm | 432 mm | 470 mm | 521 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 130 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1144 mm | 1172 mm | 1200 mm | 1233 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 676 mm | 712 mm | 724 mm | 761 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 160 cm | 170 cm | 180 cm |
| Rider Max Height | 165 cm | 175 cm | 185 cm | 198 cm |
About this model
LAUFEY H10 completes the Orbea Laufey model. Orbea released 26 bikes variations of this model so far. You can easily view all of the Orbea Laufey bikes models from 2020, here.
Model range prices
Orbea LAUFEY H30 2020 is the cheapest bike model and costs 1599$. Orbea LAUFEY H LTD 2020 is the most expensive one and costs 2499$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1999$. Comparing this to the average Trail bike price, we see that the price is 38.17% lower.
LAUFEY H10 components
Fork
The Marzocchi Bomber Z2 is included from the factory. It has a travel distance of 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The wheels on LAUFEY H10 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The LAUFEY H10 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 150 cm – 198 cm (4.92 ft – 6.5 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
A dropper post is included with the LAUFEY H10. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
