Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork RockShox 30 Silver TK
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea MX Alloy only disc
Suspension Fork
RockShox 30 Silver TK 100 Air Remote QR
Drivetrain
Rear Derailleur
Shimano XT SGS Shadow Direct Mount
Front Derailleur
Shimano Deore M6025 31.8mm
Shift Levers
Shimano Deore M6000
Cassette
Shimano HG50 11-36t 10-Speed
Crank
Prowheel Zephyr-501-TT 22x36t
Chain
Fsa Team Issue
Pedals
VP-537 Black
Wheels
Rims
Orbea Black Rock 23c Disc
Tires
Kenda K1153 2.35" 30TPI
Brakes
Brakes
Shimano MT201 Hydraulic Disc
Cockpit
Stem
Orbea OC-II
Handlebar
Orbea OC-I Riser 720mm
Headset
1-1/8" Semi-Integrated
Seat
Saddle
Selle Royal 2062 HRN
Seatpost
Orbea OC-I 27.2x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.5 mm | 1.57 mm |
| Bottom Bracket Height | 312.5 mm | 312.5 mm | 312.5 mm |
| Front Center | 623 mm | 639 mm | 662 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 91 mm | 86 mm | 53 mm |
| Stack | 588 mm | 598 mm | 607 mm |
| Reach | 375 mm | 399 mm | 386 mm |
| Top Tube Length | 542 mm | 569 mm | 590 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 388 mm | 430 mm | 460 mm |
| Head Tube Angle | 69 ° | 70 ° | 70 ° |
| Head Tube Length | 102 mm | 108 mm | 118 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1064 mm | 1080 mm | 1103 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm |
| Standover Height | 795 mm | 820 mm | 839 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
MX 10 27.5 is part of the Orbea Mx model. Orbea released 76 bikes variations of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Orbea MX 20 XC 2019 is the most economical model, with a starting price of 399$. Orbea MX 10 29 2019 on the other hand costs 999$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Orbea released this model in 2019, its price was 999$. Comparing the average cost of a Crosscountry bike to this one, you will see that MX 10 27.5 price is 90.69% lower.
Overview of components
Fork
This bike has the RockShox 30 Silver TK fork installed. The fork’s travel is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The MX 10 27.5 2019 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea MX 10 27.5 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
