Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox 30 Silver TK
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea MX Alloy only disc
Suspension Fork
RockShox 30 Silver TK 100 Air Remote QR
Drivetrain
Rear Derailleur
Shimano XT SGS Shadow Direct Mount
Front Derailleur
Shimano Deore M6025 31.8mm
Shift Levers
Shimano Deore M6000
Cassette
Shimano HG50 11-36t 10-Speed
Crank
Prowheel Zephyr-501-TT 22x36t
Chain
Fsa Team Issue
Pedals
VP-537 Black
Wheels
Rims
Orbea Black Rock 23c Disc
Tires
Kenda K1153 2.35" 30TPI
Brakes
Brakes
Shimano MT201 Hydraulic Disc
Cockpit
Stem
Orbea OC-II
Handlebar
Orbea OC-I Riser 720mm
Headset
1-1/8" Semi-Integrated
Seat
Saddle
Selle Royal 2062 HRN
Seatpost
Orbea OC-I 27.2x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.64 mm | 1.6 mm | 1.53 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm |
| Front Center | 636 mm | 656 mm | 697 mm |
| Rake | 46 mm | 46 mm | 46 mm |
| Trail | 87 mm | 87 mm | 87 mm |
| Stack | 619 mm | 629 mm | 651 mm |
| Reach | 377 mm | 393 mm | 426 mm |
| Top Tube Length | 555 mm | 574 mm | 614 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 470 mm | 540 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 104 mm | 115 mm | 138 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1074 mm | 1094 mm | 1135 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 819 mm | 833 mm | 877 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
MX 10 29 completes the Orbea Mx model. Orbea released 76 bikes variations of this model so far. Take a sneak peek at all Orbea Mx bikes models from 2019, by clicking here.
Model range prices
Orbea MX 20 XC 2019 is the cheapest bike model and costs 399$. Orbea MX 10 27.5 2019 is the most expensive one and costs 999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Orbea MX 10 29 price was 999$. Comparing this to the average Crosscountry bike price, we see that the price is 90.69% smaller.
MX 10 29 components
Fork
The MX 10 29 comes factory-installed with the RockShox 30 Silver TK fork. This has a travel range of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The MX 10 29 2019 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The MX 10 29 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
MX 10 29 comes in 3 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
