Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Fork SunTour XCR 32 -
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 166cm
MD
164cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea MX Alloy only disc
Suspension Fork
SR Suntour XCR32 RL Coil w/Preload adjuster 100mm QR
Drivetrain
Rear Derailleur
Shimano Deore M5100 SGS Shadow Plus
Shift Levers
Shimano Deore M5100
Cassette
Shimano CS-M5100 11-51t 11-Speed
Crank
Shimano M5100 32t
Chain
KMC X11
Wheels
Rims
Orbea Black Rock 23c Disc
Tires
Kenda K1153 2.35" 30TPI
Brakes
Brakes
Shimano MT201 Hydraulic Disc
Cockpit
Stem
Alloy 31.8mm interface 7º
Handlebar
Alloy Flat 31.8mm 720mm
Headset
VP-Z104PD 1-1/8" Semi-Cartridge
Seat
Saddle
Selle Royal 2058 DRN
Seatpost
Alloy 27.2 Offset 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.5 mm |
| Bottom Bracket Height | 312.5 mm | 312.5 mm |
| Front Center | 623 mm | 639 mm |
| Rake | 42 mm | 42 mm |
| Trail | 91 mm | 86 mm |
| Stack | 588 mm | 598 mm |
| Reach | 375 mm | 399 mm |
| Top Tube Length | 542 mm | 569 mm |
| Seat Tube Angle | 74 ° | 74 ° |
| Seat Tube Length | 388 mm | 430 mm |
| Head Tube Angle | 69 ° | 70 ° |
| Head Tube Length | 102 mm | 108 mm |
| Chainstay Length | 445 mm | 445 mm |
| Wheelbase | 1064 mm | 1080 mm |
| Bottom Bracket Drop | 45 mm | 45 mm |
| Standover Height | 795 mm | 820 mm |
| Wheels | 27" | 27" |
| Rider Min Height | 155 cm | 164 cm |
| Rider Max Height | 166 cm | 180 cm |
About this model
MX 20 27.5 belongs to the Orbea Mx model. 76 bikes variations carry this model name so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Orbea MX 50 27.5 2021 is the most affordable bike of this model and has a price of 656$. On the other hand, Orbea MX 20 27.5 2021, is the most expensive and costs 996$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2021 and its price was 996$. Doing a quick comparison, we notice that MX 20 27.5 price is 91.27% lower than the average cost of a Crosscountry bike.
Overview of components
Fork
The SunTour XCR 32 is included from the factory. It has a travel distance of mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the MX 20 27.5 model has 27.5″ aluminum wheels. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The MX 20 27.5 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
MX 20 27.5 comes in 2 sizes, that range from 155 cm – 180 cm (5.09 ft – 5.91 ft). In short, you can easily find one that suits you.
