Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Groupset Altus -
Suspension Rigid -
Drivetrain 1 × 8 -
Brakes Rim
Sizing
Recommended size guide.
16"
100cm - 116cm
20"
114cm - 136cm
24"
134cm - 156cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Hexatubing Aluminum. Mx Compact Geometry. Internal cable routing. Only disc.
Suspension Fork
Orbea Alu 20"
Drivetrain
Rear Derailleur
Shimano Altus M310
Shift Levers
Shimano M310
Cassette
Shimano HG31 11-34t 8-Speed
Crank
Alloy 34t (127)
Chain
KMC Z8
Pedals
Resine BMX
Wheels
Rims
Orbea Alu 20"
Tires
Kenda 1047 20x2.10" 60TPI Wire DTC
Brakes
Brakes
Alu V-Brake
Brake Levers
Orbea
Cockpit
Stem
Orbea OC-II
Handlebar
Orbea OC-I Riser 540mm
Headset
1-1/8" Semi-Integrated
Seat
Saddle
Velo 7087
Seatpost
Orbea OC 27.2x250mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 20" | 24" | 26" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.12 mm | 1.33 mm | 1.42 mm | 1.46 mm |
| Bottom Bracket Height | 192 mm | 237 mm | 272 mm | 280 mm |
| Front Center | 433 mm | 488 mm | 554 mm | 594 mm |
| Rake | 35 mm | 33 mm | 36 mm | 39 mm |
| Stack | 317 mm | 419 mm | 494 mm | 532 mm |
| Reach | 282 mm | 314 mm | 347 mm | 365 mm |
| Top Tube Length | 379.3 mm | 439 mm | 513 mm | 530 mm |
| Seat Tube Angle | 73.2 ° | 73 ° | 72 ° | 73 ° |
| Seat Tube Length | 207 mm | 257 mm | 329 mm | 367 mm |
| Head Tube Angle | 71 ° | 72 ° | 71 ° | 70 ° |
| Head Tube Length | 90 mm | 95 mm | 90 mm | 90 mm |
| Chainstay Length | 305 mm | 337 mm | 381 mm | 419 mm |
| Wheelbase | 738 mm | 824 mm | 933 mm | 1009 mm |
| Bottom Bracket Drop | 8 mm | 16 mm | 30 mm | 45 mm |
| Standover Height | 436 mm | 527 mm | 654 mm | 707 mm |
| Wheels | 20" | 20" | 20" | 20" |
| Rider Min Height | 100 cm | 114 cm | 134 cm | 154 cm |
| Rider Max Height | 116 cm | 136 cm | 156 cm | cm |
About this model
MX 20 TEAM completes the Orbea Mx model. 76 bikes variations carry this model name so far. Take a sneak peek at all Orbea Mx bikes models from 2019, by clicking here.
Model range prices
Orbea MX 20 XC 2019 is the most affordable bike of this model and has a price of 399$. On the other hand, Orbea MX 10 27.5 2019, is the most expensive and costs 999$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Mountain bikes average price
According to our math, the average price for a trustworthy Mountain bike is 616$. However, this doesn’t mean that if you spend less money on a Mountain bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2019 and its price was 439$. If we compare this with the average Mountain bike cost we notice that the price is 40.32% lower.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
MX 20 TEAM components
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
As for the wheels, Orbea MX 20 TEAM 2019, has a 20″ aluminum model. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
When you want to stop the bike in time, the brakes are vital. The MX 20 TEAM has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
