Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Groupset Altus -
Suspension Rigid -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
16"
100cm - 116cm
20"
114cm - 136cm
24"
134cm - 156cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Hexatubing Aluminum. Mx Compact Geometry. Internal cable routing. Only disc.
Suspension Fork
Orbea Alu 20" only disc
Drivetrain
Rear Derailleur
Shimano Altus M310
Shift Levers
Shimano M310
Cassette
Shimano HG31 11-34t 8-Speed
Crank
Alloy 34t (127)
Chain
KMC Z8
Pedals
Resine BMX
Wheels
Rims
Mach1 Klixx 23c Tubeless Ready
Tires
Kenda 1047 20x2.10" 60TPI Wire DTC
Brakes
Brakes
Shimano M396 Hydraulic Disc
Cockpit
Stem
Orbea OC-II
Handlebar
Orbea OC-I Riser 540mm
Headset
1-1/8" Semi-Integrated
Seat
Saddle
Velo 7087
Seatpost
Orbea OC-I 27.2x250mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 20" | 24" | 26" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.12 mm | 1.33 mm | 1.42 mm | 1.46 mm |
| Bottom Bracket Height | 192 mm | 237 mm | 272 mm | 280 mm |
| Front Center | 433 mm | 488 mm | 554 mm | 594 mm |
| Rake | 35 mm | 33 mm | 36 mm | 39 mm |
| Stack | 317 mm | 419 mm | 494 mm | 532 mm |
| Reach | 282 mm | 314 mm | 347 mm | 365 mm |
| Top Tube Length | 379.3 mm | 439 mm | 513 mm | 530 mm |
| Seat Tube Angle | 73.2 ° | 73 ° | 72 ° | 73 ° |
| Seat Tube Length | 207 mm | 257 mm | 329 mm | 367 mm |
| Head Tube Angle | 71 ° | 72 ° | 71 ° | 70 ° |
| Head Tube Length | 90 mm | 95 mm | 90 mm | 90 mm |
| Chainstay Length | 305 mm | 337 mm | 381 mm | 419 mm |
| Wheelbase | 738 mm | 824 mm | 933 mm | 1009 mm |
| Bottom Bracket Drop | 8 mm | 16 mm | 30 mm | 45 mm |
| Standover Height | 436 mm | 527 mm | 654 mm | 707 mm |
| Wheels | 20" | 20" | 20" | 20" |
| Rider Min Height | 100 cm | 114 cm | 134 cm | 154 cm |
| Rider Max Height | 116 cm | 136 cm | 156 cm | cm |
Model Overview
MX 20 TEAM DISC belongs to the Orbea Mx model. 76 bikes variations carry this model name so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Orbea MX 20 XC 2018 is the most economical model, with a starting price of 399$. Orbea MX 10 29 2018 on the other hand costs 999$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Mountain bikes average price
Our math shows that the average cost of a dependable Mountain bike is 616$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Mountain bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2018 and its price was 539$. Doing a quick comparison, we notice that MX 20 TEAM DISC price is 14.29% smaller than the average cost of a Mountain bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
As for the wheels, Orbea MX 20 TEAM DISC 2018, has a 20″ aluminum model. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
