Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Fork SunTour XCT -
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea MX Alloy only disc
Suspension Fork
SR Suntour XCT 30 Coil 100mm QR
Drivetrain
Rear Derailleur
Shimano Altus M310
Front Derailleur
Shimano Altus M313 31.8mm
Shift Levers
Shimano M310
Cassette
Shimano HG200 12-32t 8-Speed
Crank
Shimano TY301 24x34x42t
Chain
KMC X8
Pedals
VP-537 Black
Wheels
Rims
Mach1 ER20 19c
Tires
Kenda K1153 2.35" 22TPI
Brakes
Brakes
Shimano MT200 Hydraulic Disc
Cockpit
Stem
Orbea OC
Handlebar
Orbea OC Riser 720mm
Headset
1-1/8" Semi-Integrated
Seat
Saddle
Selle Royal 2073
Seatpost
Orbea OC 27.2x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.5 mm | 1.57 mm |
| Bottom Bracket Height | 312.5 mm | 312.5 mm | 312.5 mm |
| Front Center | 623 mm | 639 mm | 662 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 91 mm | 86 mm | 53 mm |
| Stack | 588 mm | 598 mm | 607 mm |
| Reach | 375 mm | 399 mm | 386 mm |
| Top Tube Length | 542 mm | 569 mm | 590 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 388 mm | 430 mm | 460 mm |
| Head Tube Angle | 69 ° | 70 ° | 70 ° |
| Head Tube Length | 102 mm | 108 mm | 118 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1064 mm | 1080 mm | 1103 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm |
| Standover Height | 795 mm | 820 mm | 839 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
MX 50 27.5 is an Orbea Mx model. Orbea launched 76 bikes of this model so far. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
The most economical model, the Orbea MX 20 XC 2018 has a starting price of 399$. Orbea MX 10 29 2018 on the other hand is the most expensive at 999$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 649$. Comparing this to the average Crosscountry bike price, we see that the price is 193.53% smaller.
Overview of components
Fork
Orbea MX 50 27.5 2018 bike is equipped with the SunTour XCT fork, and has mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When it comes to wheels, the MX 50 27.5 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea MX 50 27.5 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
MX 50 27.5 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
