Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Fork SunTour -
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea MX Alloy only disc
Suspension Fork
SR Suntour XCE 28 Coil 100mm QR
Drivetrain
Rear Derailleur
Shimano TY-300
Front Derailleur
Shimano Altus M313 31.8mm
Shift Levers
Shimano M310
Cassette
Shimano HG200 12-32t 7-Speed
Crank
Shimano TY301 24x34x42t
Chain
KMC Z7 GYBR
Pedals
VP-537 Black
Wheels
Rims
Mach1 ER20 19c
Tires
Kenda K1153 2.35" 22TPI
Brakes
Brakes
Shimano MT200 Hydraulic Disc
Cockpit
Stem
Alloy 31.8 A:6º
Handlebar
Orbea OC Riser 720mm
Headset
1-1/8" Semi-Integrated
Seat
Saddle
Selle Royal 2073
Seatpost
Orbea OC 27.2x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.64 mm | 1.6 mm | 1.53 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm |
| Front Center | 636 mm | 656 mm | 697 mm |
| Rake | 46 mm | 46 mm | 46 mm |
| Trail | 87 mm | 87 mm | 87 mm |
| Stack | 619 mm | 629 mm | 651 mm |
| Reach | 377 mm | 393 mm | 426 mm |
| Top Tube Length | 555 mm | 574 mm | 614 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 470 mm | 540 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 104 mm | 115 mm | 138 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1074 mm | 1094 mm | 1135 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 819 mm | 833 mm | 877 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
MX 60 29 is an Orbea Mx model. Orbea released 76 bikes variations of this model so far. You can easily view all of the Orbea Mx bikes models from 2019, here.
Model range prices
The most economical model, the Orbea MX 20 XC 2019 has a starting price of 399$. Orbea MX 10 27.5 2019 on the other hand is the most expensive at 999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Orbea released this model in 2019, its price was 599$. Doing a quick comparison, we notice that MX 60 29 price is 218.03% smaller than the average cost of a Crosscountry bike.
Overview of components
Fork
The SunTour is included from the factory. It has a travel distance of mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the MX 60 29 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea MX 60 29 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, it won’t be difficult to find the right one for you.
