Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Fox Factory Float 34
-
Groupset XX1 Eagle, X01 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Occam AM OMR 150mm travel UFO 27.5 Boost 12x148 PF
Suspension Fork
Fox 34 Float Factory 150 FIT4 3-Pos-Adj QR15x110 Kashima
Rear Shock
Fox DPX2 Factory 3-Position Adjust Evol Kashima custom tune 210x55mm
Drivetrain
Rear Derailleur
SRAM XX1 Eagle Gold
Front Derailleur
N/A
Shift Levers
SRAM X01 Eagle
Cassette
SRAM XX1 XG-1299 Eagle 10-50t 12-Speed
Crank
SRAM XX1 Eagle Dub Black Boost 32t Rotor QX1 DM SRAM 32t Chainring (EXTRA)
Chain
SRAM XX1 Eagle 12-Speed Gold
Chain Guide
OneUp Components ISCG05 Guide
Pedals
N/A
Wheels
Front Hub
DT Swiss XMC-1200 Spline, 110x15mm Boost front, 148x12mm Boost rear, IS (6-bolt) rotors
Rear Hub
DT Swiss XMC-1200 Spline, 110x15mm Boost front, 148x12mm Boost rear, IS (6-bolt) rotors
Rims
DT XMC-1200 Spline 30c TLR 15/110mm IS (6-bolt)
Tires
Maxxis Ardent 2.40" TLR 60 Tpi Exo Dual
Brakes
Brakes
Avid Guide RSC Hydraulic Disc Shimano XTR M9120 Hydraulic Disc
Brake Levers
Avid Guide RSC Hydraulic
Cockpit
Stem
Race Face Turbine 35mm interface
Handlebar
Race Face Next R 35 20mm Rise 780mm
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Italia XR Trail Selle Italia X-LR Ti Flow
Seatpost
Crank brothers Highline 31.6x425/150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.35 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm |
| Front Center | 696 mm | 724 mm | 748 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 113 mm | 114 mm | 113 mm |
| Stack | 578 mm | 588 mm | 597 mm |
| Reach | 399 mm | 424 mm | 443 mm |
| Top Tube Length | 556 mm | 583 mm | 605 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 393 mm | 432 mm | 470 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1114 mm | 1142 mm | 1166 mm |
| Bottom Bracket Drop | 13 mm | 13 mm | 13 mm |
| Standover Height | 706 mm | 734 mm | 761 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
OCCAM AM M-LTD is an Orbea Occam model. 80 bikes variations carry this model name so far. Take a sneak peek at all Orbea Occam bikes models from 2018, by clicking here.
Model range prices
Orbea OCCAM TR H50 2018 is the most affordable bike of this model and has a price of 2499$. On the other hand, Orbea OCCAM AM M-LTD 2018, is the most expensive and costs 7999$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Enduro bikes average price
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Orbea OCCAM AM M-LTD price was 7999$. In conclusion, this bike price is 122.26% more expensive than the price of the average Enduro bike.
OCCAM AM M-LTD components
Fork
This bike has the Fox Factory Float 34 fork installed. The fork’s travel is 150mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this bike is Fox DPX2 Factory 3-Position Adjust Evol, with a travel distance of 150mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The OCCAM AM M-LTD 2018 bike is equipped with 27.5″ carbon wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea OCCAM AM M-LTD is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Orbea OCCAM AM M-LTD comes with a dropper post. Therefore, climbing or descending will be a breeze.
