Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork Fox Factory Float 36
-
Groupset X01 Eagle AXS, X0 -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Occam OMR. Concentric Boost 12x148 rear axle. Pure Trail geometry. Internal cable routing. Asymmetric design. 29" wheels
Suspension Fork
Fox 36 Float Factory 160 Grip2 QR15x110 Kashima
Rear Shock
Fox DHX Factory 2-Position Adjust custom tune 210x55mm
Drivetrain
Rear Derailleur
SRAM X0 Eagle AXS
Shift Levers
SRAM AXS Pod
Cassette
SRAM GX-1275 Eagle 10-52t 12-Speed
Crank
SRAM X0 Eagle Dub Black 32t
Chain
SRAM GX Eagle 12-Speed
Wheels
Rims
Oquo Mountain Control MC32TEAM
Tires
Maxxis Dissector 2.40" 60 TPI 3CMaxxTerra Exo TLR
Brakes
Brakes
SRAM Code Silver Hydraulic Disc
Cockpit
Stem
OC Mountain Control MC10 Alu SL, 0º
Handlebar
OC Mountain Control MC10 Carbon, Rise 20, Width 800
Grips
Ergon GE10
Headset
Alloy 1-1/2", Black Oxidated Bearing
Seat
Saddle
ERGON SM Enduro Comp Men S/M
Seatpost
Fox Transfer Factory Kashima Dropper 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.416 mm | 1.444 mm | 1.35 mm | 1.374 mm | 1.299 mm | 1.323 mm | 1.253 mm | 1.275 mm |
| Bottom Bracket Height | 350 mm | 342 mm | 350 mm | 342 mm | 350 mm | 342 mm | 350 mm | 342 mm |
| Front Center | 760 mm | 762 mm | 787 mm | 789 mm | 816 mm | 819 mm | 846 mm | 848 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 134 mm | 137 mm | 134 mm | 136 mm | 135 mm | 136 mm | 134 mm | 137 mm |
| Stack | 616 mm | 621 mm | 621 mm | 625 mm | 630 mm | 635 mm | 639 mm | 644 mm |
| Reach | 435 mm | 430 mm | 460 mm | 455 mm | 485 mm | 480 mm | 510 mm | 505 mm |
| Top Tube Length | 571 mm | 572 mm | 597 mm | 598 mm | 624 mm | 625 mm | 651 mm | 653 mm |
| Seat Tube Angle | 77.5 ° | 77 ° | 77.5 ° | 77 ° | 77.5 ° | 77 ° | 77.5 ° | 77 ° |
| Seat Tube Length | 405 mm | 405 mm | 415 mm | 415 mm | 430 mm | 430 mm | 460 mm | 460 mm |
| Head Tube Angle | 64.5 ° | 64 ° | 64.5 ° | 64 ° | 64.5 ° | 64 ° | 64.5 ° | 64 ° |
| Head Tube Length | 95 mm | 95 mm | 100 mm | 100 mm | 110 mm | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1199 mm | 1200 mm | 1226 mm | 1227 mm | 1255 mm | 1257 mm | 1285 mm | 1286 mm |
| Bottom Bracket Drop | 28 mm | 36 mm | 28 mm | 36 mm | 28 mm | 36 mm | 28 mm | 36 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
Model Overview
OCCAM LT M-TEAM belongs to the Orbea Occam model. Orbea launched 91 bikes of this model so far. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
Orbea OCCAM SL H30 2024 is the most economical model, with a starting price of 2964$. Orbea OCCAM SL M-LTD 2024 on the other hand costs 10588$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro bikes average price
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Orbea released this model in 2024, its price was 8470$. In conclusion, this bike price is 135.34% more expensive than the price of the average Enduro bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
This bike has the Fox Factory Float 36 fork installed. The fork’s travel is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Orbea OCCAM LT M-TEAM bike has the Fox DHX Factory 2-Position Adjust custom tune 210x55mm model installed, and has a travel of 150mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The wheels on OCCAM LT M-TEAM are the 29″ carbon type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The OCCAM LT M-TEAM has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
