Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Performance Float 34
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM-XC
155cm - 170cm
SM-TR
155cm - 170cm
MD-XC
165cm - 180cm
MD-TR
165cm - 180cm
LG-TR
178cm - 190cm
LG-XC
178cm - 190cm
XL-XC
185cm - 198cm
XL-TR
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Oiz Hydro High Polished, Alloy link, Boost, PF BB, UFO2, I-Line shock
Suspension Fork
Fox 34 Float SC Performance 120 Grip Remote Push-Unlock QR15x110
Rear Shock
Fox i-line DPS Performance 120mm Remote Push-Unlock Evol custom tune190x45mm
Drivetrain
Rear Derailleur
Shimano XT M8100 SGS Shadow Plus
Shift Levers
Shimano XT M8100 I-Spec EV
Cassette
Shimano CS-M7100 10-51t 12-Speed
Crank
Shimano XT M8100 32t
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano M6100
Chain Guide
Orbea OC chainguide
Wheels
Rims
Race Face AR 30c Tubeless Ready
Tires
Maxxis Forekaster 2.35" FB 120 TPI Dual Exo
Brakes
Brakes
Shimano M6100 Hydraulic Disc
Cockpit
Stem
OC1 31.8mm interface -7º
Handlebar
OC1 Flat 31.8mm 740mm
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Fizik Taiga S-alloy rail
Seatpost
OC MC20 Mountain Control Dropper, 31,6mm, 125mm travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM-XC | SM-TR | MD-XC | MD-TR | LG-TR | LG-XC | XL-XC | XL-TR |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.53 mm | 1.35 mm | 1.4 mm | 1.36 mm | 1.31 mm | 1.29 mm | 1.33 mm |
| Bottom Bracket Height | 327 mm | 334 mm | 327 mm | 334 mm | 334 mm | 327 mm | 327 mm | 334 mm |
| Front Center | 663 mm | 669 mm | 692 mm | 699 mm | 723 mm | 717 mm | 742 mm | 749 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 89 mm | 86 mm | 97 mm | 104 mm | 105 mm | 97 mm | 97 mm | 105 mm |
| Stack | 591 mm | 598 mm | 596 mm | 603 mm | 613 mm | 605 mm | 619 mm | 627 mm |
| Reach | 412 mm | 392 mm | 440 mm | 430 mm | 451 mm | 461 mm | 481 mm | 471 mm |
| Top Tube Length | 569 mm | 572 mm | 598 mm | 601 mm | 615 mm | 622 mm | 646 mm | 648 mm |
| Seat Tube Angle | 75 ° | 74 ° | 75 ° | 74 ° | 74 ° | 75 ° | 75 ° | 74 ° |
| Seat Tube Length | 405 mm | 405 mm | 432 mm | 432 mm | 470 mm | 470 mm | 520 mm | 520 mm |
| Head Tube Angle | 69 ° | 68 ° | 69 ° | 68 ° | 68 ° | 69 ° | 69 ° | 68 ° |
| Head Tube Length | 90 mm | 90 mm | 95 mm | 95 mm | 105 mm | 105 mm | 120 mm | 120 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1099 mm | 1106 mm | 1128 mm | 1136 mm | 1160 mm | 1153 mm | 1178 mm | 1186 mm |
| Bottom Bracket Drop | 47 mm | 40 mm | 47 mm | 40 mm | 40 mm | 47 mm | 47 mm | 40 mm |
| Standover Height | 727 mm | 729 mm | 737 mm | 744 mm | 754 mm | 747 mm | 754 mm | 761 mm |
| Wheels | 27" | 27" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 155 cm | 165 cm | 165 cm | 178 cm | 178 cm | 185 cm | 185 cm |
| Rider Max Height | 170 cm | 170 cm | 180 cm | 180 cm | 190 cm | 190 cm | 198 cm | 198 cm |
Model Overview
OIZ H10 TR completes the Orbea Oiz model. Orbea released 78 bikes variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Orbea OIZ H30 2022 is the cheapest bike model and costs 2760$. Orbea OIZ M LTD 2022 is the most expensive one and costs 10192$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Orbea released this model in 2022, its price was 3715$. If we compare this with the average Trail bike cost we notice that the price is 34.5% higher.
Overview of components
Fork
Orbea OIZ H10 TR 2022 bike is equipped with the Fox Performance Float 34 fork, and has 120mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the Fox i-line DPS Performance 120mm Remote rear shock model, which has a travel of 120mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The wheels on OIZ H10 TR are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The OIZ H10 TR comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 8 sizes. They vary from 155 cm – 198 cm (5.09 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Orbea OIZ H10 TR includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
