Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Rhythm Float 32
-
Groupset GX Eagle, Truvativ Stylo -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
178cm - 190cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Oiz Hydro High Polished, Alloy link, Boost, BSA, SIC, UFO, I-Line shock
Suspension Fork
Fox 32 Float Rhythm 120 Remote Push-Unlock QR15x110
Rear Shock
Fox i-line DPS Performance 120mm Remote Push-Unlock Evol custom tune190x45mm
Drivetrain
Rear Derailleur
SRAM GX Eagle Lunar
Shift Levers
SRAM GX Eagle Lunar
Cassette
SRAM PG-1230 Eagle 11-50t 12-Speed
Crank
SRAM Stylo 6K Eagle Dub Boost 32t Steel
Bottom Bracket
BSA, 73mm, threaded
Chain
SRAM NX Eagle 12-Speed
Wheels
Rims
Alloy, Tubeless, 25c, 32H
Tires
Maxxis Rekon Race 2.35" 120 TPI Exo TLR
Brakes
Brakes
Shimano M6100 Hydraulic Disc
Cockpit
Stem
OC Mountain Performance MP21, -6º
Handlebar
Alloy, 31.8mm, Flat, 740mm, Sweep 9
Headset
FSA 1-1/2" Integrated Aluminium Cup
Seat
Saddle
Selle Italia Model X FecAlloy Rail 145x248mm
Seatpost
OC Mountain Control MC20, 31.6mm, Dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.34 mm | 1.3 mm | 1.25 mm |
| Bottom Bracket Height | 333 mm | 333 mm | 333 mm | 333 mm |
| Front Center | 709 mm | 736 mm | 762 mm | 790 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 111 mm | 111 mm | 111 mm | 111 mm |
| Stack | 589 mm | 593 mm | 603 mm | 612 mm |
| Reach | 418 mm | 443 mm | 465 mm | 489 mm |
| Top Tube Length | 561 mm | 587 mm | 612 mm | 638 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 410 mm | 432 mm | 460 mm | 510 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1135 mm | 1162 mm | 1188 mm | 1216 mm |
| Bottom Bracket Drop | 42 mm | 42 mm | 42 mm | 42 mm |
| Standover Height | 722 mm | 736 mm | 739 mm | 736 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 178 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 198 cm |
Model Overview
OIZ H20 belongs to the Orbea Oiz model. Orbea released 78 bikes variations of this model so far. Take a sneak peek at all Orbea Oiz bikes models from 2023, by clicking here.
Model range prices
Orbea OIZ H30 2023 is the most affordable bike of this model and has a price of 3299$. On the other hand, Orbea OIZ M LTD 2023, is the most expensive and costs 10499$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Orbea OIZ H20 price was 3599$. If we compare this with the average Trail bike cost we notice that the price is 30.3% higher.
Overview of components
Fork
The Fox Rhythm Float 32 is included from the factory. It has a travel distance of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the Fox i-line DPS Performance 120mm Remote rear shock model, which has a travel of 120mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The OIZ H20 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The OIZ H20 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 155 cm – 198 cm (5.09 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
The Orbea model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
