Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Factory Float 34
-
Groupset XTR, Race Face -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM-XC
155cm - 170cm
SM-TR
155cm - 170cm
MD-XC
165cm - 180cm
MD-TR
165cm - 180cm
LG-XC
178cm - 190cm
LG-TR
178cm - 190cm
XL-XC
185cm - 198cm
XL-TR
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Oiz Carbon OMX, Fiberlink, Boost, PF BB, UFO2, I-line shock
Suspension Fork
Fox 34 Float SC Factory 120 FIT4 Remote-Adj Push-Unlock QR15x110
Rear Shock
Fox i-line DPS Factory 120mm Remote Push-Unlock Evol Kashima custom tune 190x45mm
Drivetrain
Rear Derailleur
Shimano XTR M9100 SGS Shadow Plus
Shift Levers
Shimano XT M8100 I-Spec EV
Cassette
Shimano CS-M8100 10-51t 12-Speed
Crank
Race Face Next-SL 34t
Chain
Shimano M8100
Chain Guide
Orbea OC chainguide
Wheels
Rims
OC XC TEAM, 30 mm internal width, Tubeless ready, 28H
Tires
Maxxis Rekon Race 2.35" 120 TPI Exo TLR
Brakes
Brakes
Shimano XT M8100 Hydraulic Disc
Cockpit
Stem
OC MP20 Mountain Performance, -8º
Handlebar
OC MP10 Mountain Performance Carbon, Width 760, Sweep 9
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Selle Italia SLR Boost Fill Titanium Rail 316 Ø7 mm
Seatpost
OC MC20 Mountain Control Dropper, 31,6mm, 125mm travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM-XC | SM-TR | MD-XC | MD-TR | LG-XC | LG-TR | XL-XC | XL-TR |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.49 mm | 1.35 mm | 1.4 mm | 1.31 mm | 1.36 mm | 1.29 mm | 1.33 mm |
| Bottom Bracket Height | 327 mm | 334 mm | 327 mm | 334 mm | 327 mm | 334 mm | 327 mm | 334 mm |
| Front Center | 663 mm | 669 mm | 693 mm | 699 mm | 717 mm | 723 mm | 742 mm | 749 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 96 mm | 104 mm | 96 mm | 104 mm | 97 mm | 105 mm | 97 mm | 105 mm |
| Stack | 591 mm | 598 mm | 596 mm | 603 mm | 605 mm | 613 mm | 619 mm | 627 mm |
| Reach | 412 mm | 402 mm | 440 mm | 430 mm | 461 mm | 451 mm | 481 mm | 471 mm |
| Top Tube Length | 569 mm | 572 mm | 598 mm | 601 mm | 622 mm | 624 mm | 646 mm | 648 mm |
| Seat Tube Angle | 75 ° | 74 ° | 75 ° | 74 ° | 75 ° | 74 ° | 75 ° | 74 ° |
| Seat Tube Length | 405 mm | 405 mm | 432 mm | 432 mm | 470 mm | 470 mm | 520 mm | 520 mm |
| Head Tube Angle | 69 ° | 68 ° | 69 ° | 68 ° | 69 ° | 68 ° | 69 ° | 68 ° |
| Head Tube Length | 90 mm | 90 mm | 95 mm | 95 mm | 105 mm | 105 mm | 120 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1094 mm | 1101 mm | 1124 mm | 1131 mm | 1148 mm | 1155 mm | 1173 mm | 1181 mm |
| Bottom Bracket Drop | 47 mm | 40 mm | 47 mm | 40 mm | 47 mm | 40 mm | 47 mm | 40 mm |
| Standover Height | 722 mm | 729 mm | 737 mm | 744 mm | 747 mm | 754 mm | 754 mm | 761 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 155 cm | 165 cm | 165 cm | 178 cm | 178 cm | 185 cm | 185 cm |
| Rider Max Height | 170 cm | 170 cm | 180 cm | 180 cm | 190 cm | 190 cm | 198 cm | 198 cm |
Model Overview
OIZ M PRO TR is an Orbea Oiz model. 78 bikes variations carry this model name so far. You can easily view all of the Orbea Oiz bikes models from 2022, here.
Model range prices
Orbea OIZ H30 2022 is the most affordable bike of this model and has a price of 2760$. On the other hand, Orbea OIZ M LTD 2022, is the most expensive and costs 10192$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2022 and its price was 6370$. In conclusion, this bike price is 130.63% more expensive than the price of the average Trail bike.
OIZ M PRO TR components
Fork
The OIZ M PRO TR comes factory-installed with the Fox Factory Float 34 fork. This has a travel range of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the Fox i-line DPS Factory 120mm Remote model, with a travel of 120mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When it comes to wheels, the OIZ M PRO TR bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The OIZ M PRO TR has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Orbea OIZ M PRO TR bike has 8 sizes, in the range of 155 cm – 198 cm (5.09 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
Orbea OIZ M PRO TR comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
