Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Performance Float 34
-
Groupset GX Eagle AXS, Truvativ Stylo -
Suspension Full -
Battery SRAM Powerpack -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
178cm - 190cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Oiz Carbon OMR, Fiberlink, Boost, BSA, SIC, UFO, I-line shock
Suspension Fork
Fox 34 Float SC Performance 120 Grip Remote Push-Unlock QR15x110
Rear Shock
Fox i-line DPS Performance 120mm Remote Push-Unlock Evol custom tune190x45mm
Drivetrain
Rear Derailleur
SRAM GX1 Eagle AXS Lunar
Shift Levers
SRAM GX Eagle AXS
Cassette
SRAM PG-1230 Eagle 11-50t 12-Speed
Crank
SRAM Stylo 6K Eagle Dub Boost 32t Steel
Bottom Bracket
BSA, 73mm, threaded
Chain
SRAM GX Eagle 12-Speed
Wheels
Rims
OQUO Mountain Performance MP28PRO
Tires
Maxxis Rekon Race 2.40" WT 120 TPI Exo TLR
Brakes
Brakes
Shimano XT M8100 Hydraulic Disc
Cockpit
Stem
OC Mountain Performance MP21, -6º
Handlebar
OC Mountain Performance MP30, Width 760
Headset
Alloy 1-1/2", Black Oxidated Bearing
Seat
Saddle
Fizik Taiga S-alloy rail
Seatpost
OC Mountain Control MC20, 31.6mm, Dropper
Motor & Battery
Battery
SRAM Powerpack
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.32 mm | 1.28 mm | 1.25 mm |
| Bottom Bracket Height | 333 mm | 333 mm | 333 mm | 333 mm |
| Front Center | 709 mm | 734 mm | 760 mm | 790 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 111 mm | 111 mm | 111 mm | 111 mm |
| Stack | 601 mm | 601 mm | 611 mm | 624 mm |
| Reach | 430 mm | 455 mm | 477 mm | 501 mm |
| Top Tube Length | 580 mm | 603 mm | 628 mm | 655 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 405 mm | 432 mm | 460 mm | 510 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 115 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1143 mm | 1168 mm | 1194 mm | 1224 mm |
| Bottom Bracket Drop | 42 mm | 42 mm | 42 mm | 42 mm |
| Standover Height | 736 mm | 746 mm | 746 mm | 755 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 178 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 198 cm |
Model Overview
OIZ M11 AXS belongs to the Orbea Oiz model. Orbea launched 78 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Orbea OIZ H30 2023 is the cheapest bike model and costs 3299$. Orbea OIZ M LTD 2023 is the most expensive one and costs 10499$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5699$. Comparing this to the average Trail bike price, we see that the price is 106.34% more expensive.
OIZ M11 AXS components
Fork
The Fox Performance Float 34 is included from the factory. It has a travel distance of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Orbea OIZ M11 AXS bike has the Fox i-line DPS Performance 120mm Remote model installed, and has a travel of 120mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The OIZ M11 AXS 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The OIZ M11 AXS comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 155 cm – 198 cm (5.09 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Orbea model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
