Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Performance Float 34
-
Groupset SLX, Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
178cm - 190cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Oiz Carbon OMR, Fiberlink, Boost, BSA, SIC, UFO, I-line shock
Suspension Fork
Fox 34 Float SC Performance 120 Grip Remote Push-Unlock QR15x110
Rear Shock
Fox i-line DPS Performance 120mm Remote Push-Unlock Evol custom tune190x45mm
Drivetrain
Rear Derailleur
Shimano SLX M7100 SGS Shadow Plus
Shift Levers
Shimano Deore M6100 I-Spec EV
Cassette
Shimano CS-M7100 10-51t 12-Speed
Crank
Shimano MT611 32t
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano M6100
Wheels
Rims
Alloy, Tubeless, 25c, 32H
Tires
Maxxis Rekon Race 2.35" 120 TPI Exo TLR
Brakes
Brakes
Shimano M6100 Hydraulic Disc
Cockpit
Stem
OC Mountain Performance MP21, -6º
Handlebar
OC Mountain Performance MP30, Width 760
Headset
Alloy 1-1/2", Black Oxidated Bearing
Seat
Saddle
Selle Italia Model X FecAlloy Rail 145x248mm
Seatpost
OC Mountain Control MC20, 31.6mm, Dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.32 mm | 1.28 mm | 1.25 mm |
| Bottom Bracket Height | 333 mm | 333 mm | 333 mm | 333 mm |
| Front Center | 709 mm | 734 mm | 760 mm | 790 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 111 mm | 111 mm | 111 mm | 111 mm |
| Stack | 601 mm | 601 mm | 611 mm | 624 mm |
| Reach | 430 mm | 455 mm | 477 mm | 501 mm |
| Top Tube Length | 580 mm | 603 mm | 628 mm | 655 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 405 mm | 432 mm | 460 mm | 510 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 115 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1143 mm | 1168 mm | 1194 mm | 1224 mm |
| Bottom Bracket Drop | 42 mm | 42 mm | 42 mm | 42 mm |
| Standover Height | 736 mm | 746 mm | 746 mm | 755 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 178 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 198 cm |
Model Overview
OIZ M30 completes the Orbea Oiz model. Orbea launched 78 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
The most economical model, the Orbea OIZ H30 2023 has a starting price of 3299$. Orbea OIZ M LTD 2023 on the other hand is the most expensive at 10499$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Orbea released this model in 2023, its price was 4399$. Doing a quick comparison, we notice that OIZ M30 price is 59.27% more expensive than the average cost of a Trail bike.
Overview of components
Fork
The Fox Performance Float 34 is included from the factory. It has a travel distance of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Orbea OIZ M30 bike has the Fox i-line DPS Performance 120mm Remote model installed, and has a travel of 120mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the OIZ M30 bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 155 cm – 198 cm (5.09 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the OIZ M30. Therefore, climbing or descending will be a breeze.
