Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 27.5" -
Fork Suntour XCR Air -
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
145cm - 160cm
SM
155cm - 170cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Onna Alloy, Dropout 9x135, BSA BB, Internal cable routing
Suspension Fork
SR Suntour XCR Air Lor 100mm QR
Drivetrain
Rear Derailleur
Shimano Deore M5120 SGS Shadow Plus
Shift Levers
Shimano Deore M4100
Cassette
Sun Race 11-46t 10-Speed
Crank
Alloy forged 30t
Bottom Bracket
BSA, 73mm, threaded
Chain
KMC X10
Pedals
VP-537 Black
Wheels
Rims
Orbea Black Rock 23c Disc
Tires
Kenda K1153 2.35" 30TPI
Brakes
Brakes
Shimano MT200 Hydraulic Disc
Cockpit
Stem
Alloy 31.8mm interface 7º
Handlebar
Alloy Flat 31.8mm 720mm
Headset
1"-1/2 Semi-Integrated
Seat
Saddle
Selle Royal 2058 DRN
Seatpost
Alloy 27.2 Offset 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM |
|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.53 mm |
| Bottom Bracket Height | 312 mm | 312 mm |
| Front Center | 623 mm | 647 mm |
| Rake | 42 mm | 42 mm |
| Trail | 95 mm | 95 mm |
| Stack | 583 mm | 592 mm |
| Reach | 366 mm | 386 mm |
| Top Tube Length | 527 mm | 550 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° |
| Seat Tube Length | 350 mm | 388 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° |
| Head Tube Length | 95 mm | 105 mm |
| Chainstay Length | 431 mm | 431 mm |
| Wheelbase | 1050 mm | 1074 mm |
| Bottom Bracket Drop | 45 mm | 45 mm |
| Standover Height | 669 mm | 706 mm |
| Wheels | 27" | 27" |
| Rider Min Height | 145 cm | 155 cm |
| Rider Max Height | 160 cm | 170 cm |
Model Overview
ONNA 20 27.5 belongs to the Orbea Onna model. There are 25 bikes that carry this model name. You can easily view all of the Orbea Onna bikes models from 2022, here.
Model range prices
The most economical model, the Orbea ONNA 27 XS JUNIOR 50 2022 has a starting price of 668$. Orbea ONNA 10 2022 on the other hand is the most expensive at 1337$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1061$. In conclusion, this bike price is 79.55% smaller than the price of the average Crosscountry bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
ONNA 20 27.5 components
Fork
Orbea ONNA 20 27.5 2022 bike is equipped with the Suntour XCR Air fork, and has mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The ONNA 20 27.5 2022 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The ONNA 20 27.5 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 2 sizes available for this model. Rider height can be anywhere between 145 cm – 170 cm (4.76 ft – 5.58 ft). In short, it won’t be difficult to find the right one for you.
