Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Fork Suntour XCT -
Groupset Altus, Alivio -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
145cm - 160cm
SM
155cm - 170cm
SM
155cm - 170cm
MD
165cm - 180cm
LG
175cm - 190cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Onna Alloy, Dropout 9x135, BSA BB, Internal cable routing
Suspension Fork
SR Suntour XCT 30 Coil 100mm QR
Drivetrain
Rear Derailleur
Shimano Altus M2000 SGS Shadow
Front Derailleur
Shimano M2020 31.8mm
Shift Levers
Shimano Alivio SL-M3100
Cassette
Sun Race CSM989 11-36t 9-Speed
Crank
Alloy forged 22x36t 9S
Bottom Bracket
BSA, 73mm, threaded
Chain
KMC X9
Pedals
VP-537 Black
Wheels
Rims
Orbea Black Rock 23c Disc
Tires
Kenda K1153 2.35" 30TPI
Brakes
Brakes
Shimano MT200 Hydraulic Disc
Cockpit
Stem
Alloy 31.8mm interface 7º
Handlebar
Alloy Flat 31.8mm 720mm
Headset
1"-1/8 Semi-Integrated
Seat
Saddle
Selle Royal 2058 DRN
Seatpost
Alloy 27.2 Offset 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.53 mm | 1.58 mm | 1.47 mm | 1.42 mm | 1.37 mm |
| Bottom Bracket Height | 312 mm | 312 mm | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 623 mm | 647 mm | 661 mm | 689 mm | 714 mm | 747 mm |
| Rake | 42 mm | 42 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 95 mm | 95 mm | 98 mm | 98 mm | 98 mm | 98 mm |
| Stack | 583 mm | 592 mm | 618 mm | 618 mm | 628 mm | 642 mm |
| Reach | 366 mm | 386 mm | 391 mm | 419 mm | 441 mm | 469 mm |
| Top Tube Length | 527 mm | 550 mm | 562 mm | 590 mm | 615 mm | 647 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 350 mm | 388 mm | 388 mm | 430 mm | 470 mm | 540 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 95 mm | 105 mm | 95 mm | 95 mm | 105 mm | 120 mm |
| Chainstay Length | 431 mm | 431 mm | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1050 mm | 1074 mm | 1094 mm | 1122 mm | 1147 mm | 1181 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 64 mm | 64 mm | 64 mm | 64 mm |
| Standover Height | 669 mm | 706 mm | 706 mm | 740 mm | 771 mm | 827 mm |
| Wheels | 27" | 27" | 29" | 29" | 29" | 29" |
| Rider Min Height | 145 cm | 155 cm | 155 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 160 cm | 170 cm | 170 cm | 180 cm | 190 cm | 195 cm |
Model Overview
ONNA 40 completes the Orbea Onna model. 25 bikes variations carry this model name so far. Take a sneak peek at all Orbea Onna bikes models from 2022, by clicking here.
Model range prices
Orbea ONNA 27 XS JUNIOR 50 2022 is the most economical model, with a starting price of 668$. Orbea ONNA 10 2022 on the other hand costs 1337$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2022 and its price was 911$. Comparing this to the average Crosscountry bike price, we see that the price is 109.11% lower.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
The ONNA 40 comes factory-installed with the Suntour XCT fork. This has a travel range of mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The wheels on ONNA 40 are the 27.5″ aluminum type. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Orbea ONNA 40 bike has 6 sizes, in the range of 145 cm – 195 cm (4.76 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
