Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 27.5" -
Fork Suntour XCT -
Groupset Altus, Shimano -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
145cm - 160cm
SM
155cm - 170cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Onna Alloy, Dropout 9x135, BSA BB, Internal cable routing
Suspension Fork
SR Suntour XCT 30 Coil 100mm QR
Drivetrain
Rear Derailleur
Shimano Altus M2000 SGS Shadow
Front Derailleur
Shimano M2020 31.8mm
Shift Levers
Shimano Alivio SL-M3100
Cassette
Sun Race CSM989 11-36t 9-Speed
Crank
Alloy forged 22x36t 9S
Bottom Bracket
BSA, 73mm, threaded
Chain
KMC X9
Pedals
VP-537 Black
Wheels
Rims
Orbea Black Rock 23c Disc
Tires
Kenda K1153 2.35" 30TPI
Brakes
Brakes
Shimano MT200 Hydraulic Disc
Cockpit
Stem
Alloy 31.8mm interface 7º
Handlebar
Alloy Flat 31.8mm 720mm
Headset
1"-1/8 Semi-Integrated
Seat
Saddle
Selle Royal 2058 DRN
Seatpost
Alloy 27.2 Offset 0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM |
|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.53 mm |
| Bottom Bracket Height | 312 mm | 312 mm |
| Front Center | 623 mm | 647 mm |
| Rake | 42 mm | 42 mm |
| Trail | 95 mm | 95 mm |
| Stack | 583 mm | 592 mm |
| Reach | 366 mm | 386 mm |
| Top Tube Length | 527 mm | 550 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° |
| Seat Tube Length | 350 mm | 388 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° |
| Head Tube Length | 95 mm | 105 mm |
| Chainstay Length | 431 mm | 431 mm |
| Wheelbase | 1050 mm | 1074 mm |
| Bottom Bracket Drop | 45 mm | 45 mm |
| Standover Height | 669 mm | 706 mm |
| Wheels | 27" | 27" |
| Rider Min Height | 145 cm | 155 cm |
| Rider Max Height | 160 cm | 170 cm |
About this model
ONNA 40 27.5 completes the Orbea Onna model. There are 25 bikes that carry this model name. You can easily view all of the Orbea Onna bikes models from 2022, here.
Model range prices
Orbea ONNA 27 XS JUNIOR 50 2022 is the cheapest bike model and costs 668$. Orbea ONNA 10 2022 is the most expensive one and costs 1337$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Orbea ONNA 40 27.5 price was 795$. In conclusion, this bike price is 139.62% lower than the price of the average Crosscountry bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
The fork installed on this bike is the Suntour XCT model. The travel on this model is mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The ONNA 40 27.5 2022 bike is equipped with 27.5″ aluminum wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea ONNA 40 27.5 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This bike is available in 2 sizes. They vary from 145 cm – 170 cm (4.76 ft – 5.58 ft). In short, it won’t be difficult to find the right one for you.
