Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED eTAP -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
47cm
155cm - 161cm
49cm
159cm - 168cm
51cm
165cm - 174cm
53cm
171cm - 181cm
55cm
178cm - 187cm
57cm
184cm - 193cm
60cm
190cm - 207cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Orca carbon OMX Disc, monocoque construction, HS 1,5", BB 386mm, powermeter compatible, Rear Thru Axle 12x142mm, thread M12x2 P1, internal cable routing, EC/DC compatible, OMX specific seat tube.
Suspension Fork
steerer, tapered 1-1/8" - 1,5", carbon dropouts, Thru axle 12x100mm, thread M12x2 P1
Drivetrain
Rear Derailleur
SRAM Red eTAP
Front Derailleur
SRAM Red eTAP
Shift Levers
SRAM Red eTap AXS
Cassette
SRAM XG-1290 10-28t 12-Speed
Crank
SRAM Red Dub 35x48t
Bottom Bracket
386EVO, 86mm, press-fit
Chain
SRAM Red 12-Speed
Wheels
Rims
Mavic Ksyrium Pro Carbon Disc UST CL
Tires
Mavic Yksion Pro 700x25
Brakes
Brakes
SRAM Red eTap AXS
Cockpit
Stem
Orbea ICR -8º
Handlebar
OC2 Road Carbon, reach 80mm, drop 125mm
Headset
Acros Alloy 1-1/2" Internal Cable Routing
Seat
Saddle
Selle Italia SLR Boost SuperFlow L Carbon Keramic Rail Ø7 x 9 mm
Seatpost
Orbea Orca OMX SB0-25mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 51cm | 53cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.37 mm | 1.4 mm | 1.43 mm | 1.46 mm | 1.48 mm | 1.52 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 575 mm | 579 mm | 583 mm | 583 mm | 594 mm | 604 mm | 618 mm |
| Rake | 48 mm | 48 mm | 48 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 65 mm | 62 mm | 57 mm | 59 mm | 58 mm | 57 mm | 57 mm |
| Stack | 512.06 mm | 521 mm | 539 mm | 558 mm | 577.92 mm | 596 mm | 622 mm |
| Reach | 376.08 mm | 381.56 mm | 386 mm | 391 mm | 397.02 mm | 404 mm | 410 mm |
| Top Tube Length | 516.45 mm | 529.24 mm | 541.84 mm | 554.51 mm | 566.43 mm | 582.13 mm | 595.97 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.7 ° | 73.5 ° | 73.5 ° | 73.2 ° | 73.2 ° |
| Seat Tube Length | 440 mm | 460 mm | 480 mm | 500 mm | 520 mm | 540 mm | 570 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.2 ° | 72.8 ° | 73 ° | 73.2 ° | 73.2 ° |
| Head Tube Length | 105.6 mm | 113.2 mm | 129.6 mm | 147.9 mm | 168 mm | 186.2 mm | 213.3 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 977 mm | 982 mm | 986 mm | 987 mm | 997 mm | 1007 mm | 1021 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 732 mm | 745 mm | 764 mm | 784 mm | 805 mm | 823 mm | 851 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 159 cm | 165 cm | 171 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 161 cm | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 207 cm |
Model Overview
ORCA M11eLTD-D belongs to the Orbea Orca model. Orbea released 214 bikes variations of this model so far. You can easily view all of the Orbea Orca bikes models from 2020, here.
Model range prices
Orbea ORCA M40 2020 is the most economical model, with a starting price of 1799$. Orbea ORCA M11eLTD-D 2020 on the other hand costs 9599$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Race bikes average price
If you want an acceptable Race bike you should know that the average price is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 9599$. Comparing this to the average Race bike price, we see that the price is 186.54% more expensive.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
ORCA M11eLTD-D components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The ORCA M11eLTD-D 2020 bike is equipped with 700c carbon wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Orbea ORCA M11eLTD-D is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
ORCA M11eLTD-D comes in 7 sizes, that range from 155 cm – 207 cm (5.09 ft – 6.79 ft). In conclusion, you won’t have a problem finding one that suits you.
