Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM/MD
170cm - 180cm
MD/LG
175cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Ordu carbon OMX Disc, monocoque construction, HS 1" - 1 1/8" mini tapered, BB 386mm, powermeter compatible, Thru Axle 12x142mm, thread M12x2 P1, Speed release compatible dropout, Internal Cable Routing.
Suspension Fork
Orbea Ordu OMX ICR fork 2021, full carbon, 1" head tube, Thru axle 12x100m, thread M12x2P1, Speed release compatible dropout. UCI Legal.
Drivetrain
Rear Derailleur
Shimano Dura-Ace Di2 R9250
Front Derailleur
Shimano Dura-Ace Di2 R9250
Shift Levers
Shimano R9180
Cassette
Shimano Dura-Ace R9200 11-30t 12-Speed
Crank
Shimano Dura-Ace R9200 36x52t
Bottom Bracket
386EVO, 86mm, press-fit
Chain
Shimano CN-9100
Wheels
Rims
Shimano R9270 C50 Disc Carbon TL CL
Tires
Vittoria Rubino Pro IV G2.0 700x25c
Brakes
Brakes
Shimano R9270 Hydraulic Disc
Cockpit
Handlebar
Orbea Ordu OMX
Headset
FSA 1-1/8"-1" Integrated Aluminium Cup
Seat
Saddle
Fizik Argo Vento R5 size 140mm
Seatpost
Orbea Ordu OMX, w/Micro tilt adjustment
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM/MD | MD/LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 0.75 mm | 0.776 mm | 0.776 mm | 0.821 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm | 261 mm |
| Front Center | 578 mm | 614 mm | 614 mm | 654 mm |
| Trail | 60 mm | 60 mm | 60 mm | 60 mm |
| Stack | 481 mm | 516 mm | 516 mm | 566 mm |
| Reach | 641 mm | 665 mm | 665 mm | 689 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Length | 59 mm | 96 mm | 96 mm | 149 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 971 mm | 1007 mm | 1007 mm | 1048 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 746 mm | 781 mm | 781 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Max Height | 171 cm | 180 cm | 185 cm | cm |
Model Overview
ORDU M10iLTD is an Orbea Ordu model. Orbea launched 35 bikes of this model so far. Take a sneak peek at all Orbea Ordu bikes models from 2023, by clicking here.
Model range prices
Orbea ORDU M30iLTD 2023 is the most affordable bike of this model and has a price of 7299$. On the other hand, Orbea ORDU M10iLTD 2023, is the most expensive and costs 10999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Triathlon bikes
According to our math, the average price for a trustworthy Triathlon bike is 4177$. However, even if your budget is less than the average, you might still be able to get a top-quality Triathlon bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Orbea released this model in 2023, its price was 10999$. In conclusion, this bike price is 163.32% higher than the price of the average Triathlon bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
ORDU M10iLTD components
Fork material
ORDU M10iLTD has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The ORDU M10iLTD 2023 bike is equipped with 700c carbon wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
