Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
XS
153cm - 164cm
SM
161cm - 176cm
MD
173cm - 186cm
LG
184cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ordu carbon OME, monocoque, 1-1/8" head tube, PF 86mm, powermeter compatible, internal cable routing, EC/DC compatible, 130mm rear spacing, vertical dropouts, UCI legal, external battery compatible.
Suspension Fork
Ordu OME carbon fork, aluminum steerer, 1-1/8" head tube
Drivetrain
Rear Derailleur
Shimano Ultegra R8000 SS
Front Derailleur
Shimano Ultegra R8000
Shift Levers
Shimano Bar End SL-BSR1
Cassette
Shimano 105 R7000 11-28t 11-Speed
Crank
FSA Gossamer Pro 36x52t
Bottom Bracket
BB86/BB92, press-fit
Chain
Fsa Team Issue
Pedals
N/A
Wheels
Rims
Vision Team 30 Comp Clincher
Tires
Vittoria Rubino Foldable 700x23 60TPI G+
Brakes
Brakes
Shimano 105 R7000
Brake Levers
Vision Trimax Aero Alloy
Cockpit
Stem
Orbea OC-III
Handlebar
Vision Trimax Alloy
Headset
FSA 1-1/8" Integrated Carbon Cup
Seat
Saddle
Prologo Zero Tri T2,0
Seatpost
Ordu OME Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.33 mm | 1.31 mm | 1.31 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 575 mm | 608 mm | 616 mm | 650 |
| Rake | 53 mm | 54 mm | 44 mm | 46 mm |
| Trail | 63 mm | 59 mm | 57 mm | 55 mm |
| Stack | 496 mm | 524 mm | 552 mm | 581 mm |
| Reach | 366 mm | 393 mm | 420 mm | 444 mm |
| Top Tube Length | 471 mm | 504 mm | 540 mm | 578 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 77 ° |
| Seat Tube Length | 520 mm | 550 mm | 575 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 73 ° | 73 ° |
| Head Tube Length | 92 mm | 120 mm | 139 mm | 169 mm |
| Chainstay Length | 406 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 970 mm | 1003 mm | 1011 mm | 1045 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 73 mm |
| Standover Height | 750 mm | 778 mm | 803 mm | 836 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 153 cm | 161 cm | 173 cm | 184 cm |
| Rider Max Height | 164 cm | 176 cm | 186 cm | 195 cm |
About this model
ORDU M20 completes the Orbea Ordu model. Orbea launched 35 bikes of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Orbea ORDU M30 2018 is the most affordable bike of this model and has a price of 2399$. On the other hand, Orbea ORDU M10iTEAM 2018, is the most expensive and costs 8999$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Triathlon bikes average price
If you want to purchase a solid Triathlon bike, it is important to know that the average cost is 4177$. However, even if your budget is less than the average, you might still be able to get a top-quality Triathlon bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Orbea released this model in 2018, its price was 2699$. In conclusion, this bike price is 54.76% lower than the price of the average Triathlon bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
ORDU M20 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
As for the wheels, Orbea ORDU M20 2018, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Orbea ORDU M20 bike has 4 sizes, in the range of 153 cm – 195 cm (5.02 ft – 6.4 ft). In short, you can easily find one that suits you.
