Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Sizing
Recommended size guide.
XS
152cm - 165cm
SM
160cm - 172cm
MD
167cm - 180cm
LG
175cm - 187cm
XL
182cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ordu carbon OMP, monocoque, 1" - 1 1/8" mini tapered head tube, BB386 °46mm, powermeter compatible, internal cable routing, EC/DC compatible, 130mm rear spacing, vertical dropouts, UCI legal.
Suspension Fork
Ordu OMP carbon fork, aluminum steerer, 1" - 1 1/8" mini tapered head tube
Drivetrain
Rear Derailleur
Shimano Ultegra Di2 R8050 SS
Front Derailleur
Shimano Ultegra Di2 R8050
Shift Levers
Shimano SW-671
Cassette
Shimano Ultegra R8000 11-28t 11-Speed
Crank
Rotor Flow 36x52At Rotor Flow NOQ 34x50t Rotor Aldhu 36x52t Rotor 2INpower DM 34x50t Rotor 2INpower DM 36x52t
Bottom Bracket
BB86/BB92, press-fit
Chain
Fsa Team Issue
Pedals
N/A
Wheels
Rims
DT PR 1600 Spline 32 Fulcrum Racing Quattro Carbon DT Swiss ARC1400 Dicut 48
Tires
Hutchinson Fusion 5 All SeasonTLR 700x25
Brakes
Brakes
Tri Rig Omega X Standart
Brake Levers
Vision Trimax Aero Alloy
Cockpit
Handlebar
Vision Metron Carbon with SnakeBite stem
Headset
FSA 1-1/8"-1" Integrated Aluminium Cup
Seat
Saddle
Tgale Tirox size 132 mm Prologo Dimension T4,0 Black
Seatpost
Orbea Ordu OMP
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.26 mm | 1.26 mm | 1.26 mm | 1.26 mm | 1.28 mm |
| Bottom Bracket Height | 280 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 569 mm | 594 mm | 601 mm | 624 mm | 646 mm |
| Rake | 53 mm | 53 mm | 45 mm | 45 mm | 45 mm |
| Trail | 60 mm | 60 mm | 59 mm | 56 mm | 56 mm |
| Stack | 456 mm | 481 mm | 506 mm | 531 mm | 556 mm |
| Reach | 361 mm | 381 mm | 401 mm | 421 mm | 436 mm |
| Top Tube Length | 460 mm | 485 mm | 510 mm | 535 mm | 566 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° | 77 ° |
| Seat Tube Length | 493 mm | 508 mm | 533 mm | 559 mm | 587 mm |
| Head Tube Angle | 71 ° | 71 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 71.6 mm | 85 mm | 103.7 mm | 128 mm | 154 mm |
| Chainstay Length | 396 mm | 396 mm | 396 mm | 396 mm | 396 mm |
| Wheelbase | 957 mm | 979 mm | 986 mm | 1009 mm | 1032 mm |
| Bottom Bracket Drop | 60 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 751 mm | 766 mm | 771 mm | 816 mm | 841 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 160 cm | 167 cm | 175 cm | 182 cm |
| Rider Max Height | 165 cm | 172 cm | 180 cm | 187 cm | 195 cm |
Model Overview
ORDU M20iTEAM is part of the Orbea Ordu model. 35 bikes variations carry this model name so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
The most economical model, the Orbea ORDU M30 2018 has a starting price of 2399$. Orbea ORDU M10iTEAM 2018 on the other hand is the most expensive at 8999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Triathlon bikes
Our math shows that the average cost of a dependable Triathlon bike is 4177$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Triathlon bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2018 and its price was 5999$. Comparing the average cost of a Triathlon bike to this one, you will see that ORDU M20iTEAM price is 43.62% more expensive.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The wheels on ORDU M20iTEAM are the 700c carbon type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea ORDU M20iTEAM has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
Sizes
ORDU M20iTEAM comes in 5 sizes, that range from 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
