Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Factory Float 38
-
Groupset XT, Race Face -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
150cm - 171cm
SM
150cm - 171cm
LG
169cm - 190cm
MD
160cm - 181cm
LG
169cm - 190cm
LG
169cm - 190cm
XL
179cm - 200cm
XL
179cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Monocoque Race Carbon. Advanced Dynamics 160mm suspension technology. 29" wheels.Concentric Boost 12x148 rear axle. Pure Enduro geometry. Internal cable routing. ISCG05
Suspension Fork
Fox 38 Float Factory 170 Grip2 QR15x110 Kashima
Rear Shock
Fox Float X2 Factory 2-Position Adjust Kashima custom tune 230x60mm
Drivetrain
Rear Derailleur
Shimano XT M8100 SGS Shadow Plus
Shift Levers
Shimano XT M8100 I-Spec EV
Cassette
Shimano CS-M8100 10-51t 12-Speed
Crank
Race Face Next-R 32t
Chain
Shimano M7100
Chain Guide
e*thirteen CL52 30-36t black
Wheels
Rims
Race Face TURBINE-R 30 TLR IS (29" Front / 27,5" Rear)
Tires
Maxxis Minion DHR II 2.40" WT FB 120 TPI 3C Maxx Terra Exo+ TR
Brakes
Brakes
Shimano XT M8120 Hydraulic Disc
Cockpit
Stem
Race Face Turbine R 35mm interface
Handlebar
Race Face Next R 35 20mm Rise 800mm
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
Fizik Taiga Kium rail
Seatpost
Fox Transfer Factory Kashima Dropper 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM | LG | MD | LG | LG | XL | XL |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.45 mm | 1.37 mm | 1.39 mm | 1.31 mm | 1.34 mm | 1.27 mm | 1.29 mm |
| Bottom Bracket Height | 350 mm | 343 mm | 350 mm | 343 mm | 350 mm | 343 mm | 350 mm | 343 mm |
| Front Center | 763 mm | 765 mm | 792 mm | 794 mm | 821 mm | 824 mm | 851 mm | 853 mm |
| Rake | 42 mm | 43 mm | 41 mm | 42 mm | 41 mm | 43 mm | 42 mm | 43 mm |
| Trail | 132 mm | 135 mm | 133 mm | 136 mm | 133 mm | 135 mm | 132 mm | 135 mm |
| Stack | 617 mm | 621 mm | 626 mm | 630 mm | 635 mm | 639 mm | 644 mm | 648 mm |
| Reach | 433 mm | 428 mm | 458 mm | 453 mm | 483 mm | 478 mm | 508 mm | 503 mm |
| Top Tube Length | 570 mm | 571 mm | 597 mm | 598 mm | 624 mm | 625 mm | 651 mm | 653 mm |
| Seat Tube Angle | 77.5 ° | 77 ° | 77.5 ° | 77 ° | 77.5 ° | 77 ° | 77.5 ° | 77 ° |
| Seat Tube Length | 415 mm | 415 mm | 415 mm | 415 mm | 435 mm | 435 mm | 460 mm | 460 mm |
| Head Tube Angle | 64.5 ° | 64 ° | 64.5 ° | 64 ° | 64.5 ° | 64 ° | 64.5 ° | 64 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 100 mm | 110 mm | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 438 mm | 436 mm | 438 mm | 436 mm | 438 mm | 436 mm | 438 mm | 436 mm |
| Wheelbase | 1200 mm | 1199 mm | 1229 mm | 1228 mm | 1258 mm | 1258 mm | 1288 mm | 1287 mm |
| Bottom Bracket Drop | 28 mm | 35 mm | 28 mm | 35 mm | 28 mm | 35 mm | 28 mm | 35 mm |
| Standover Height | 735 mm | 742 mm | 735 mm | 742 mm | 752 mm | 759 mm | 772 mm | 779 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 150 cm | 169 cm | 160 cm | 169 cm | 169 cm | 179 cm | 179 cm |
| Rider Max Height | 171 cm | 171 cm | 190 cm | 181 cm | 190 cm | 190 cm | 200 cm | 200 cm |
About this model
RALLON M-TEAM completes the Orbea Rallon model. Orbea released 25 bikes variations of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Orbea RALLON M20 2022 is the most affordable bike of this model and has a price of 4883$. On the other hand, Orbea RALLON M-LTD 2022, is the most expensive and costs 10086$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro bikes average price
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2022 and its price was 7431$. In conclusion, this bike price is 106.47% higher than the price of the average Enduro bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The Fox Factory Float 38 is included from the factory. It has a travel distance of 170mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Orbea RALLON M-TEAM bike has the Fox Float X2 Factory 2-Position Adjust model installed, and has a travel of 160mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The wheels on RALLON M-TEAM are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 8 sizes. They vary from 150 cm – 200 cm (4.92 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Orbea RALLON M-TEAM comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
