Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Travel Rear 167mm -
Fork Fox Performance Float 38
-
Groupset XT, Race Face -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM High
150cm - 171cm
SM Low
150cm - 171cm
LG High
169cm - 190cm
LG Low
169cm - 190cm
LG High
169cm - 190cm
LG Low
169cm - 190cm
XL High
180cm - 200cm
XL Low
180cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Orbea Monocoque Race Carbon. Advanced Dynamics 167mm suspension technology. 29" wheels.Concentric Boost 12x148 rear axle. Pure Enduro geometry. Internal cable routing. ISCG05
Suspension Fork
Fox 38 Float Performance 170 Grip 3-Position QR15x110
Rear Shock
Fox FLOAT X Performance 2-Position Evol LV custom tune 230x62.5mm
Drivetrain
Rear Derailleur
Shimano XT M8100 SGS Shadow Plus
Shift Levers
Shimano XT M8100 I-Spec EV
Cassette
Shimano CS-M7100 10-51t 12-Speed
Crank
Race Face Turbine 32t
Chain
Shimano M7100
Chain Guide
e*thirteen CL55 30-36t black
Wheels
Rims
Oquo Mountain Control MC32TEAM (29" Front / Rear)
Tires
Maxxis Minion DHR II 2.40" WT FB 120 TPI 3C Maxx Terra Exo+ TR
Brakes
Brakes
Shimano XT M8120 Hydraulic Disc
Cockpit
Stem
OC Mountain Control MC20, 0º
Handlebar
OC Mountain Control MC20 Alu SL, Rise20, Width 800
Grips
OC Lock On
Headset
Acros Alloy 1-1/8 - 1-1/2" Integrated
Seat
Saddle
ERGON SM Enduro
Seatpost
OC Mountain Control MC21, 31.6mm, Dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | LG High | LG Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.423 mm | 1.423 mm | 1.365 mm | 1.365 mm | 1.313 mm | 1.313 mm | 1.267 mm | 1.267 mm |
| Bottom Bracket Height | 350 mm | 343 mm | 350 mm | 343 mm | 350 mm | 343 mm | 350 mm | 343 mm |
| Front Center | 763 mm | 764 mm | 792 mm | 793 mm | 821 mm | 822 mm | 851 mm | 852 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 143 mm | 150 mm | 144 mm | 150 mm | 144 mm | 151 mm | 144 mm | 150 mm |
| Stack | 619 mm | 619 mm | 628 mm | 628 mm | 637 mm | 637 mm | 646 mm | 646 mm |
| Reach | 435 mm | 435 mm | 460 mm | 460 mm | 485 mm | 485 mm | 510 mm | 510 mm |
| Top Tube Length | 572 mm | 572 mm | 599 mm | 599 mm | 626 mm | 626 mm | 653 mm | 653 mm |
| Seat Tube Angle | 77.5 ° | 77 ° | 77.5 ° | 77 ° | 77.5 ° | 77 ° | 77.5 ° | 77 ° |
| Seat Tube Length | 415 mm | 415 mm | 415 mm | 415 mm | 435 mm | 435 mm | 460 mm | 460 mm |
| Head Tube Angle | 64 ° | 63.5 ° | 64 ° | 63.5 ° | 64 ° | 63.5 ° | 64 ° | 63.5 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 100 mm | 110 mm | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1202 mm | 1202 mm | 1231 mm | 1231 mm | 1260 mm | 1260 mm | 1290 mm | 1290 mm |
| Bottom Bracket Drop | 28 mm | 35 mm | 28 mm | 35 mm | 28 mm | 35 mm | 28 mm | 35 mm |
| Standover Height | 737 mm | 737 mm | 737 mm | 737 mm | 754 mm | 754 mm | 774 mm | 774 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 150 cm | 169 cm | 169 cm | 169 cm | 169 cm | 180 cm | 180 cm |
| Rider Max Height | 171 cm | 171 cm | 190 cm | 190 cm | 190 cm | 190 cm | 200 cm | 200 cm |
About this model
RALLON M10 completes the Orbea Rallon model. 29 bikes variations carry this model name so far. You can easily view all of the Orbea Rallon bikes models from 2024, here.
Model range prices
Orbea RALLON M20 2024 is the most affordable bike of this model and has a price of 5294$. On the other hand, Orbea RALLON M-LTD 2024, is the most expensive and costs 11118$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Enduro bikes
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Orbea released this model in 2024, its price was 6352$. If we compare this with the average Enduro bike cost we notice that the price is 76.49% higher.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
The fork installed on this bike is the Fox Performance Float 38 model. The travel on this model is 170mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The RALLON M10 has a rear shock with a travel of 167mm. The model Fox FLOAT X Performance 2-Position Evol is the one installed in this bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The RALLON M10 2024 bike is equipped with 29″ carbon wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Orbea RALLON M10 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
RALLON M10 comes in 8 sizes, that range from 150 cm – 200 cm (4.92 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Orbea RALLON M10 comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
