Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork Fox Factory Float 34
-
Groupset EX1 -
Suspension Hardtail -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch Lithium-ion -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX 34 Float Factory, FIT4 damper, Kashima, 3-position adjust
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM EX1
Front Derailleur
N/A
Shift Levers
SRAM EX1, 8-speed
Cassette
SRAM EX1 XG-899, 11-48 tooth, 8-speed
Crank
Miranda Delta, Boost, 152mm length
Chain
SRAM EX1
Chain Guide
N/A
Pedals
VP-536, black
Wheels
Front Hub
Front: Formula DC711, Boost 15mm x 110mm, Rear: Formula DHT148, Boost 12mm x 148mm
Rear Hub
Front: Formula DC711, Boost 15mm x 110mm, Rear: Formula DHT148, Boost 12mm x 148mm
Rims
Black Jack Ready 27+ 40c Orbea Custom TLR
Spokes
2.3mm
Tires
Kenda 1184A Havok, 2.8" 120TPI/FB/TLR, eMTB specific
Brakes
Brakes
Avid Guide RE
Brake Levers
Avid Guide RE
Cockpit
Stem
Race Face Ride
Handlebar
Orbea OC-II Riser, 760mm width
Headset
FSA Integrated
Seat
Saddle
fi'zi:k Gobi M7
Seatpost
Race Face Turbine, 125mm drop
Motor & Battery
Motor
Bosch Performance CX, 250W
Battery
Bosch Lithium-ion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.85 mm | 1.72 mm | 1.68 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm |
| Stack | 628 mm | 628 mm | 651 mm |
| Reach | 339 mm | 365 mm | 388 mm |
| Top Tube Length | 535 mm | 561 mm | 591 mm |
| Seat Tube Angle | 72.9 ° | 72.9 ° | 72.9 ° |
| Seat Tube Length | 340 mm | 360 mm | 402 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 115 mm | 115 mm | 140 mm |
| Chainstay Length | 458 mm | 458 mm | 458 mm |
| Wheelbase | 1089 mm | 1115 mm | 1148 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm |
| Standover Height | 772 mm | 772 mm | 783 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Wild 10 USA belongs to the Orbea E Wild model. 77 e-bikes variations carry this model name so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Orbea Wild 30 USA 2018 is the most affordable e-bike of this model and has a price of 3799$. On the other hand, Orbea Wild FS 10 USA 2018, is the most expensive and costs 6999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail e-bikes
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2018 for 5299$. Comparing this to the average Trail e-bike price, we see that the price is 57.47% higher.
Wild 10 USA components
Fork
This e-bike has the Fox Factory Float 34 fork installed. The fork’s travel is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the Wild 10 USA model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Wild 10 USA has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Orbea Wild 10 USA comes with a dropper post. Therefore, climbing or descending will be a breeze.
